Артикул
Название
Примечание
Количество
47597103
AIR CONDITIONER
HVAC, Inc. 1 - 48
1шт.
1
322996A1
BOX
Lower Evaporator
1шт.
3
87306776
CASE ASSY.
Top, HVAC
1шт.
5
322839A1
TUBE,16mm OD, 211.5, 159.8mm Length
A/C Suction
1шт.
6
322840A1
TUBE,10mm OD, 158.4, 163.9mm L
A/C Liquid
1шт.
7
1250522C3
FITTING
Drain
2шт.
8
1977334C1
HOSE
Condensate Drain
2шт.
9
109239C2
CHECK VALVE
Evaporator Drain
2шт.
11
322989A1
GROMMET
Bulkhead, A/C
1шт.
12
322990A1
GROMMET
Bulkhead, Heater
1шт.
13
87324951
GASKET,3mm Thk
Top Cover
1шт.
16
87306495
COVER
Top
1шт.
17
87663947
BLOWER
Assembly, Cab
1шт.
17
84222524R
REMAN-BLOWER
Assembly, Cab
1шт.
17
84222524C
CORE-BLOWER
Return Number
1шт.
18
892-11006
LOCK WASHER,M6
5шт.
19
614-6016
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
4шт.
20
892-11008
LOCK WASHER,8mm ID
4шт.
21
627-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd
4шт.
22
493-81002
LOCK WASHER,Ext-Int Tooth, 1/4"
1шт.
23
829-1406
NUT,Hex, M6 x 1, Cl 10.9
2шт.
24
515-21127
CLAMP,1/2", Insul, 1/4" Bolt
1шт.
25
248-1243
GROMMET,1/2" ID x 13/16" Groove Dia, Diag Cut
2шт.
26
128485A1
O-RING,1.78mm Thk x 14mm ID, 70 Duro
Air Conditioning
1шт.
27
128484A1
O-RING,0.07" Thk x 0.426" ID, -13, Cl 5, 70 Duro
Air Conditioning
1шт.
28
105849A1
RELAY
Micro, 12 Volt
1шт.
29
323016A1
SENSOR
Probe, Temperature
1шт.
30
84381101
WIRE HARNESS
HARNESS, ATC
1шт.
31
281-14512
SELF-TAP SCREW,Hex Wash Hd, #10 x 3/4"
4шт.
32
324484A1
INSULATOR
Foil, Bottom
1шт.
33
322995A1
GASKET,3mm Thk
Flange
4шт.
35
368313A1
PLASTIC PLUG
Corner
1шт.
36
87306773
FOAM INSULATION
Foil Side
1шт.
37
47788712
SERVICE KIT
Driver Blower Linear
1шт.
38
87454442
SENSOR
Thermister Bullet
1шт.
39
47532798
MODULE
ATC Controller
1шт.
39
47532798R
REMAN-MODULE
ATC Controller
1шт.
39
47532798C
CORE-MODULE
Return Number
1шт.
40
1321290C2
HEATER HOSE,15.50 mm ID x 127.00 mm
Heater Return
1шт.
42
324022A1
HEATER HOSE,15.50 mm ID x 54.00 mm
Heater Supply
1шт.
44
324023A1
HEATER HOSE,15.50 mm ID x 64.00 mm
Heater Supply
1шт.
45
322994A1
GASKET,3mm Thk
Flange
4шт.
47
280-1448
SELF-TAP SCREW,Hex Wash Hd, #8 x 1/2"
2шт.
48
385681
NUT,M4 x 0.7, Cl 8
1шт.
Выбрано товаров: 53
