Запчасти Case IH 4430 (44.151.02) - REAR HOSE NON-PIVOT GROUP (44) - WHEELS

1

87266807

MOUNTING PLATE

Hose Pivot

1шт.

2

87615326

STOP DEVICE

Hose Stop, RH

1шт.

2

87615322

STOP DEVICE

Hose Stop, LH, Not Shown

1шт.

3

87390349

BUSHING

Hose Pivot

1шт.

4

87310608

WASHER,22mm ID x 44mm OD x 5mm Thk

22 x 44 x 5 mm, HDN, DOR

1шт.

5

86980460

BOLT,Hex, M20 x 60mm, Cl 8.8

M20 - 2.5 X 60 HH 8.8 DOR

1шт.

6

87341829

BOLT,Hex, M16 x 65mm, Cl 8.8

M16 X 65 8.8 DOR

2шт.

7

86980517

NUT,Hex, M16 - 2, Cl 8.8, DOR

2шт.

8

86980423

BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd

2шт.

9

86980516

NUT,Prev Torque, Hex, M12, 1.75 Pitch, Cl 8, DOR

2шт.
