Запчасти Case IH 4430 (35.964.07) - PARALLEL LINKAGE CYLINDER, ALL BOOMS (35) - HYDRAULIC SYSTEMS

1

87267726

CYLINDER,Double Acting, 38.1mm Rod, 723.9mm Stroke

Boom Height, 2.5 x 28.5 x 1.5

1шт.

See Fig 35.964.08 For Service Parts Breakdown

1шт.

2

87271483

BUSHING

Spring

4шт.

3

BN69951

CAP

Grease

2шт.

4

BN313038

FITTING

9/16" -18 ORB x 9/16" -18 ORB Adaptor

1шт.

5

87267325

ACCUMULATOR

10 cu. 825 psi

1шт.
