(35.964.01[01]) - LADDER LIFT CYLINDER BSN YDT036001

Запчасти Case IH 4430 (35.964.01[01]) - LADDER LIFT CYLINDER BSN YDT036001 (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 4430 - (35.964.01[01]) - LADDER LIFT CYLINDER BSN YDT036001 (35) - HYDRAULIC SYSTEMS
3
3
3
3
3
3
1
3
3
2
3
home
3
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87266443

HYDRAULIC CYLINDER,12.7mm Rod, 152.4mm Stroke

1 x 6 x 0.5, Complete, Serial Range: -YDT036000

1шт.

2

87268695

ROD,12.7mm OD x 255.78mm L

Cylinder

1шт.

3

87268691

SEAL KIT

1"

1шт.

Выбрано товаров: 3
