Запчасти Case IH 4420 (12-014) - HARNESS MOUNTING GROUP (06) - ELECTRICAL

1

NS

NOT SERVICED

Electrical Harnesses Mount

1шт.

2

87529312

WASHER,11mm ID x 24mm OD x 3mm Thk

3шт.

3

86980400

BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd

3шт.

4

86980515

NUT,Hex, M10 x 1.5, Cl 8.8, DOR

3шт.

5

87557084

CABLE TIE,14"

CABLE STRAP 14" with stainless locking clip

5шт.

6

86511444

FLANGE NUT,Hex, M6 x 1

4шт.

7

87021161

CLAMP,76.2mm, Coat, 8.7mm Bolt Hole, P Type

1шт.

8

L101181

CLAMP,0.75" D Clamping pipes x 2

Insulated, Double

1шт.
