(90.150.04) - ROOF ASSY, LOWER PANEL

Запчасти Case IH 3330 (90.150.04) - ROOF ASSY, LOWER PANEL (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH 3330 - (90.150.04) - ROOF ASSY, LOWER PANEL (90) - PLATFORM, CAB, BODYWORK AND DECALS
2
5
6
4
3
5
4
3
5
home
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87419087

ROOF

Lower Panel

1шт.

2

237275A1

STUD

M8+9.0 H/L, STEEL, DBL END COLLAR

8шт.

3

401110A2

BRACKET

WIPER MOTOR SPACER

2шт.

4

86624183

WASHER,6.6mm ID x 25mm OD x 1.6mm Thk

4шт.

5

87016559

SELF-TAP SCREW,HWH, M5.5 x 15mm

8шт.

6

449074A1

BRACKET

ROOF RETAINING

2шт.
