(75.120.73) - RESTRICTOR VALVE BREAKDOWN, "T" STYLE, 87624338

Запчасти Case IH 3330 (75.120.73) - RESTRICTOR VALVE BREAKDOWN, "T" STYLE, 87624338 (75) - SOIL PREPARATION

Схема запчастей Case IH 3330 - (75.120.73) - RESTRICTOR VALVE BREAKDOWN, "T" STYLE, 87624338 (75) - SOIL PREPARATION
3
1
2
5
home
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87624338

SHUT-OFF VALVE

"T" Style, Plunger, 2.2"Flange Port x 2" Flange Port x 2" Flange Port

1шт.

2

87658830

MOTOR-PUMP

1шт.

3

87658834

SERVICE KIT

High Flow Plunger

1шт.

4

87658832

VALVE BODY

3 Port, "T" Style

1шт.

5

87658833

CLIP

High Flow Motor

1шт.

14464481

O-RING,0.139" Thk x 1.984" ID, -226, Cl 7, 75 Duro

Between Motor And Fitting, Not Shown

1шт.

Выбрано товаров: 6
