(55.418.09) - AUTOBOOM, HEIGHT CONTROL, 90 AND 100, BOOM LEVEL ONLY

Запчасти Case IH 3330 (55.418.09) - AUTOBOOM, HEIGHT CONTROL, 90 AND 100, BOOM LEVEL ONLY (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH 3330 - (55.418.09) - AUTOBOOM, HEIGHT CONTROL, 90 AND 100, BOOM LEVEL ONLY (55) - ELECTRICAL SYSTEMS
5
2
1
home
3
7
55.418.12
75.120.71
55.418.12
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87710685

SENSOR

Ultrasonic, Right

1шт.

2

87710686

SENSOR

Ultrasonic, Left

1шт.

3

87718266

MOUNTING PLATE

Hydraulic Block, CAN

1шт.

4

84180940

WIRE HARNESS

60' Extension, Ultraglide Sensor (Not Shown)

2шт.

5

87717349

MODULE

Node, CAN, Autoboom

1шт.

87717349R

REMAN-MODULE

3330 - PATRIOT SPRAYER - 11/08-

1шт.

87717349C

CORE-MODULE

Return Number

1шт.

6

87718983

CABLE

20', CAN, Ultraglide Command (Not Shown)

1шт.

7

87717363

HYDRAULIC VALVE

Ultraglide

1шт.
