(55.404.10[01]) - BEACON LIGHT, SINGLE, BEGINNING 06/2009 AND BSN YCT032160

Запчасти Case IH 3230 (55.404.10[01]) - BEACON LIGHT, SINGLE, BEGINNING 06/2009 AND BSN YCT032160 (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH 3230 - (55.404.10[01]) - BEACON LIGHT, SINGLE, BEGINNING 06/2009 AND BSN YCT032160 (55) - ELECTRICAL SYSTEMS
8
8
8
1
8
6
8
8
8
2
8
5
7
8
4
home
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84182306

MOUNT

Beacon Light

1шт.

2

87529316

WASHER,9mm ID x 21mm OD x 2.5mm Thk

3шт.

3

86980379

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

3шт.

4

279013A3

LAMP

STROBE

1шт.

5

86639305

SET SCREW,M6 x 6mm

1шт.

6

182045A1

GROMMET

Split .57 od x .394 id

1шт.

7

87414325

SWITCH

Beacon-Strobe

1шт.

8

84127943

SERVICE KIT

Single Beacon Light, Includes Ref 1 - 7

1шт.

Выбрано товаров: 8
