Запчасти Case IH 3230 (05.102.01) - FIRE EXTINGUISHER PACKAGE BEGINNING 04/2009 (05) - SERVICE & MAINTENANCE

1

84182838

MOUNT

FIRE EXT.

1шт.

2

84182432

FOAM

CUSHION, STRIP

1шт.

3

84181073

NUT

Coupling, M8 x 1.25

2шт.

4

87529316

WASHER,9mm ID x 21mm OD x 2.5mm Thk

2шт.

5

86980378

BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd

2шт.

6

BN2293569

FIRE EXTINGUISHER

, Start Year: 01-APR-09

1шт.

7

840-1512

SCREW,Pan, M5 x 12mm, Gr 4.8

2шт.

8

87016571

NUT,M5, Cl 5

2шт.
