Артикул
Название
Примечание
Количество
1
BN67207
SLIDE
Weldment, Rail RH
1шт.
2
BN67206
SLIDE
Weldment, Rail LH
1шт.
3
BN67216
RACK
Weldment, Center Boom
1шт.
4
342503A1
BRACKET, SUPPORTING
hanger, slide rail
1шт.
5
342261A1
SUPPORT
boom rail
2шт.
6
342506A1
TUBE
mast
1шт.
7
BN325812
BRACKET
MOUNT WLDMT, ADJ (UNIBALL)
1шт.
8
439-52064
HEADED PIN,1 1/4" x 4"
2шт.
9
426-1632
BOLT,Hex, 1" - 8 x 2", Gr 8
1шт.
10
432-1632
COTTER PIN,1/4" x 2"
2шт.
11
896-11030
WASHER,33mm ID x 56mm OD x 5mm Thk
3шт.
12
495-81278
WASHER,33.53mm ID x 50.8mm OD x 3.35mm Thk
5шт.
13
86632567
HEADED PIN,30.14mm OD x 66.55mm L
2шт.
14
86986819
TUBE
Boom, Center Section
1шт.
15
BN29505
HANGER
3/4 x 3 HRFB x 10.50
4шт.
16
BN23267A
SLIDER
Nylatron .5 x 2.0 x 7.0
8шт.
17
87270296
BRACKET
Mount, Center Section
4шт.
18
BN21197
SHAFT
1" x 36"
1шт.
19
BN27328
SPRING
Compression, 1.75" od x11"
2шт.
20
280256
BOLT,Hex, 1" - 8 x 7-1/2", Gr 5
2шт.
21
BN50363
BOLT
1-14 X 6, HH, 5, Plate
4шт.
22
87529238
WASHER,1.06" ID x 2" OD x 0.13" Thk
1.0625 x 2 x 0.134 HTS DOR
20шт.
23
425-1516
JAM NUT,Jam, 1"-14, G5
8шт.
24
BN50092
NUT
Hex, 1"-8 UNC, Plated, G5
4шт.
25
87996
BOLT,Hex, 1/2" - 13 x 4 1/2", Gr 5
4шт.
26
9706716
BOLT,Hex, 1/2" - 13 x 2", Gr 5
8шт.
28
87310600
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
16шт.
29
BN55235
BOLT,Hex, 1/2"-13 x 1 1/2", G8, Full Thd
4шт.
30
86992215
LOCK NUT,1/2"-13, GC
16шт.
31
87342969
BOLT
Hex, 5/8"-18 x 2 1/4", G8
12шт.
32
87310607
WASHER,17.5mm ID x 34mm OD x 5mm Thk
17.5 x 34 x 5 MM HDN DOR
12шт.
33
87343995
NUT
Hex, 5/8"-18, GB
12шт.
34
BN50595
WASHER,1/2", Stainless
40шт.
35
BN50930
BOLT,5/16"-18 x 1.5", EH, DOR
16шт.
36
BN50057
LOCK NUT,Lock, 5/16"-18, Stainless Steel
16шт.
37
BN50601
PIN, SPLIT (COTTER)
PIN, COTTER 3/16 X 2
2шт.
38
BN314426
BUMPER, CTR SECT, SEE FIG. 08-009
1шт.
39
87545164
SPRAY, 25 MPH, SEE FIG. 10-007
1шт.
BN10465
NIPPLE, LUBE,1/4"-28 st
NIPPLE
12шт.
Associated Part of Center Section, Group
1шт.
BN313099
MOUNTING PARTS
SPRAYER, SEE FIG. 10-008
1шт.
BN50146
WASHER,3/8", Stainless
4шт.
Associated Part of Center Section, Group
1шт.
86010402
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
4шт.
Associated Part of Center Section, Group
1шт.
BN65609
SEAL
Star, 7/16 Ex Int
4шт.
Associated Part of Center Section, Group
1шт.
Выбрано товаров: 48
