(04-021) - VALVE BANK COVER GROUP, "BEFORE SERIAL # 20004"

Запчасти Case IH 3185 (04-021) - VALVE BANK COVER GROUP, "BEFORE SERIAL # 20004" Suspension & Frame

Схема запчастей Case IH 3185 - (04-021) - VALVE BANK COVER GROUP, "BEFORE SERIAL # 20004" Suspension & Frame
2/1
4/6
1/1
3/6
5/1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87272254

BRACKET

VALVE SHLD, Start Serial: 7410

1шт.

1a

BN319558

BRACKET

valve bank shield

1шт.

Indicates Old Part Number or Can Order Newer Part Number Listed above

1шт.

2

87272253

SHIELD

VALVE BANK, Start Serial: 7410

1шт.

2a

BN319146

SHIELD

valve bank

1шт.

Indicates Old Part Number or Can Order Newer Part Number Listed above

1шт.

3

BN50142

WASHER,5/16", Stainless Steel

6шт.

4

BN50476

BOLT,5/16"-18 x 0.75", Stainless

6шт.
