Запчасти Case IH 2240 (90.100.AF[01]) - ENGINE HOOD, LATCH (90) - PLATFORM, CAB, BODYWORK AND DECALS
![Схема запчастей Case IH 2240 - (90.100.AF[01]) - ENGINE HOOD, LATCH (90) - PLATFORM, CAB, BODYWORK AND DECALS](https://partsell.ru/storage/images/caseih/5136461.png)
9
6
10
4
7
4
9
6
1
7
12
1
11
3
90.100.at 03
10
2
90.100.at 04
7
10
12
6
4
3
5
11
11
6
8
90.100.av
2
2
9
7
8
2
8
11
5
1
1
8
3
5
4
9
10
3
5
home
90.100.at 02
№
Артикул
Название
Примечание
Количество
2
86632551
NUT,#10-24, GB
8шт.
3
L47159
BRACKET
Hook Anchor
4шт.
4
47422336
BRACKET
Latch
4шт.
5
L47157
HOOK
Hood Latch
4шт.
6
86980378
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
4шт.
7
87529302
WASHER,6.6mm ID x 18mm OD x 1.6mm Thk
6.6 x 18 x 1.6 mm, CST, DOR
16шт.
8
87341841
BOLT,Hex, M6 - 1 x 55mm, Class DOR
4шт.
10
87310127
SCREW,Pan HD, #10 - 24 x 1", SST
10-24 x 1.00 SST
8шт.
11
86980513
NUT,Prev Torque, Hex, M6, 1mm Pitch, Cl 8, DOR
4шт.
12
353-421
PLUG,Dome, .187" hole, Nylon
12шт.
Выбрано товаров: 12
