Запчасти Case IH 2240 (10.216.AI[01]) - FUEL TANK MOUNTING (10) - ENGINE

1

87529315

WASHER,9mm ID x 17mm OD x 2mm Thk

9 x 17 x 2mm, HTS, DOR

2шт.

2

BN67653

BUSHING

Fuel Tank

4шт.

3

84237916

RUBBER MOUNTING

Adhesive Back

4шт.

4

BN67652

PLATE

Tank Hold Down

4шт.

5

86980427

BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8

4шт.

6

87528989

WASHER,12.2mm ID x 30mm OD x 2.5mm Thk

13.5 x 30 x 2.5mm, CST, DOR

4шт.

7

86980516

NUT,Prev Torque, Hex, M12, 1.75 Pitch, Cl 8, DOR

4шт.

8

84364507

BRACKET

Tank Stabilizer

1шт.

9

86980378

BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd

2шт.

10

47486452

BRACKET

Fuel Tank

1шт.

11

86980400

BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd

4шт.

12

87529298

WASHER,11mm ID x 21mm OD x 2mm Thk

11 x 21 x 2mm, CST, DOR

4шт.

13

87344209

NUT,M10 x 1.5, Cl 10, DOR

4шт.
