Запчасти Case IH 2240 (55.100.AI[02]) - REAR MAIN FRAME WIRE HARNESS (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH 2240 - (55.100.AI[02]) - REAR MAIN FRAME WIRE HARNESS (55) - ELECTRICAL SYSTEMS
13
6
19
2
15
11
3
17
12
4
9
5
18
1
8
7
55.100.ai 01
14
10
16

Артикул

Название

Примечание

Количество

1

47600198

WIRE HARNESS

Main Frame Complete, Incl 2 - 19

1шт.

2

87696075

ELEC CONNECTOR

Female, 12 Cavity, X-606F, Tail Light Interface

1шт.

2

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

X-606F, Tail Light Interface

11шт.

2

84068583

PLUG,12 - 16 Ga, White

Cavity, X-606F, Tail Light Interface

1шт.

2

87695651

LOCKING TAB,Wedge Lock

Lock, Green, X-606F, Tail Light Interface

1шт.

3

87694153

CONTACT HOUSING,Female, 4 Cavities

X-604F, Diode Pack

1шт.

3

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

X-604F, Diode Pack

3шт.

3

84068583

PLUG,12 - 16 Ga, White

Cavity, X-604F, Diode Pack

1шт.

3

87694146

ELEC CONNECTOR,Locking, Green

Wedge, X-604F, Diode Pack

1шт.

4

87270520

DIODE

J604, Diode Receptical

1шт.

5

84159851

TERMINAL

M4 Eyelet, X-608F, Backup Alarm +

1шт.

6

84159851

TERMINAL

M4 Eyelet, X-609F, Backup Alarm -

1шт.

7

84398828

TERMINAL,3/8" Ring, SAE 8

M10 Eyelet, GD3, Clean Ground

1шт.

8

84177901

ELEC CONNECTOR

Male, 31 Cavity, X-801M, Engine Interface

1шт.

8

87695623

ELEC. TERMINAL PIN

Male, Nickel, Stamped, X-801M, Engine Interface

15шт.

8

84807680

PLUG

Cavity, X-801M, Engine Interface

14шт.

9

84244490

RING

Terminal, M12, G1-MF, Chassis Ground

1шт.

10

87695582

ELEC CONNECTOR,Female, 2 Pole

X-638F, Charge PSI

1шт.

10

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

X-638F, Charge PSI

2шт.

10

87695649

ELEC CONNECTOR,Locking, Green

Wedge, X-638F, Charge PSI

1шт.

11

87695584

CONTACT HOUSING,Male, 2 Cavities

X-638M, Shorting Jumper For Charge PSI

1шт.

11

87695623

ELEC. TERMINAL PIN

Male, Nickel, Stamped, X-638M, Shorting Jumper For Charge PSI

2шт.

11

87577731

CONTACT HOUSING,2 Pole

Wedge Lock, X-638M, Shorting Jumper For Charge PSI

1шт.

12

87695582

ELEC CONNECTOR,Female, 2 Pole

X-614F Axle In

1шт.

12

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

X-614F Axle In

2шт.

12

87695649

ELEC CONNECTOR,Locking, Green

Wedge, X-614F Axle In

1шт.

13

87695582

ELEC CONNECTOR,Female, 2 Pole

X-613F Axle Out

1шт.

13

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

X-613F Axle Out

2шт.

13

87695649

ELEC CONNECTOR,Locking, Green

Wedge, X-613F Axle Out

1шт.

14

87695582

ELEC CONNECTOR,Female, 2 Pole

X-819F, Rear

1шт.

14

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

X-819F, Rear

2шт.

14

84074638

LOCKING TAB,Locking Wedge, Green

Wedge Lock, X-819F, Rear

1шт.

15

87695582

ELEC CONNECTOR,Female, 2 Pole

X-718F, Front

1шт.

15

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

X-718F, Front

2шт.

15

87695649

ELEC CONNECTOR,Locking, Green

Wedge, X-718F, Front

1шт.

16

87695582

ELEC CONNECTOR,Female, 2 Pole

X-643F, Traction Control

1шт.

16

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

X-643F, Traction Control

2шт.

16

84074638

LOCKING TAB,Locking Wedge, Green

Wedge Lock, X-643F, Traction Control

1шт.

17

87695582

ELEC CONNECTOR,Female, 2 Pole

X-631F, Park Brake

1шт.

17

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

X-631F, Park Brake

2шт.

17

87695649

ELEC CONNECTOR,Locking, Green

Wedge, X-631F, Park Brake

1шт.

18

87700107

ELEC CONNECTOR

Female, 6 Cavity, X-628F, Hydraulic Oil Level / Temp

1шт.

18

87696954

TERMINAL,Female, Nickel, 0.35 - 1.50mm

X-628F, Hydraulic Oil Level / Temp

5шт.

18

84807680

PLUG

Sealing, Red, X-628F, Hydraulic Oil Level / Temp

1шт.

18

87705582

ELEC CONNECTOR

Wedge Lock, X-628F, Hydraulic Oil Level / Temp

1шт.

19

87692855

CONTACT HOUSING,Male, 2 Cavities

X-629F1, Hydraulic Restriction

1шт.

19

87692856

CABLE TERMINAL

Female, Tin, X-629F1, Hydraulic Restriction

2шт.

19

87680701

SEAL

Cable, Green, X-629F1, Hydraulic Restriction

2шт.

Выбрано товаров: 48
