(35.900.82) - CYLINDER, LOCKING CASTER

Запчасти Case IH 800 (35.900.82) - CYLINDER, LOCKING CASTER (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 800 - (35.900.82) - CYLINDER, LOCKING CASTER (35) - HYDRAULIC SYSTEMS
3
35.900.71
3
2
1
3
3
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87419786

HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 101.6mm Stroke

3" x 4" 3000 psi no pins

1шт.

Refer to 35.900.71

1шт.

2

3326

PIN

cylinder 1" x 2 7/8" ul hardened with snap rings

2шт.

3

87019495

SNAP RING,#98, Ext

4шт.

Выбрано товаров: 4
