(35.900.77) - HITCH, FRONT LATCH - HYDRAULIC CYLINDERS

Запчасти Case IH 800 (35.900.77) - HITCH, FRONT LATCH - HYDRAULIC CYLINDERS (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 800 - (35.900.77) - HITCH, FRONT LATCH - HYDRAULIC CYLINDERS (35) - HYDRAULIC SYSTEMS
4
1
1
5
3
3
3
3
3
4
35.900.71
5
6
6
2
7
7
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87419786

HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 101.6mm Stroke

3" x 4" 3000 psi no pins

2шт.

Refer to 35.900.71

1шт.

2

3326

PIN

cylinder 1" x 2 7/8" ul hardened with snap rings

4шт.

3

87019495

SNAP RING,#98, Ext

12шт.

4

128818

UNION,3/4" - 16 ORB x 3/4" - 16 JIC

2шт.

5

128817

HYD CONNECTOR,3/4" - 16 ORB x 9/16" - 18 JIC

2шт.

6

87503831

ARM

latch release

2шт.

7

87420071

PIN

25.4 x 50 ul

2шт.

Выбрано товаров: 8
