Запчасти Case IH 800 (35.900.02) - VALVE BLOCK - ELECTRONIC ACTUATED HYDRAULICS (35) - HYDRAULIC SYSTEMS

1

84167339

VALVE

Hydraulic Frame Assembly

1шт.

Refer to 35.900.06

1шт.

2

322896

HYD CONNECTOR,1-1/16" - 12 ORB x 1-1/16" - 12 JIC

3шт.

3

76350

HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC

3шт.

4

86509028

HYD CONNECTOR,3/4" - 16 JIC x 9/16" - 18 ORB

1шт.

5

219604

TEE,1-1/16" - 12 ORB x 1-1/16" - 12 JIC x 1-1/16" - 12 JIC

2шт.

6

87648720

REDUCER,3/4" - 16 JIC x 1-11/16" - 12 JIC

37º, 1 1/16"-12, Fem x 3/4"-16 Male

2шт.

7

128830

90 ELBOW,3/4" - 16 JIC x 3/4" - 16 ORB

2шт.

8

87495434

MOUNT

Valve Manifold

1шт.

9

280929

BOLT,Hex, 5/16" - 18 x 6", Gr 5

2шт.

10

280736

NUT,5/16"-18, GC

2шт.

11

87428328

PRESSURE SWITCH

Hydraulic Pressure, 3000 psi

2шт.

12

86513015

TEE,3/4" - 16 JIC x 3/4" - 16 JIC x 3/4" - 16 JIC

1шт.

13

70923102

REDUCER

37º, 3/4"-16, Fem x 7/16"-20 Male

1шт.

14

87393629

HYD CONNECTOR

7/16"-20 x 1/4" FPT

1шт.

15

84173956

HYD CONNECTOR

.25 FB x .25 MP

1шт.

16

86511870

TEE,3/4" - 16 JIC x 3/4" - 16 JIC x 3/4" - 16 JIC

1шт.
