Артикул
Название
Примечание
Количество
1
495137R1
SPACER
BUSHING, tube
10шт.
2
489764R1
BLOCK
2шт.
20080R1
SET SCREW
1/2 x 1-1/4 C-Z sq-hd cup-pt set
2шт.
3
478032R1
CLAMP
axle
2шт.
466971R1
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2", Gr 5
BOLT, 1/2 x 2 znd sq-nk crg
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
128228
SET SCREW,Sq Hd, 3/8"-16 x 3/4"
SCREW, 3/8 x 3/4 C-Z sq-hd cup-pt set
2шт.
4
478035R1
BEARING HOUSING,109 mm OD x 19.3 mm
disk brg inner
2шт.
5
478036R1
BEARING HOUSING,30.023 mm ID x 69 mm OD x 19.3 mm
disk brg outer
2шт.
6
478034R91
BEARING ASSY,30mm OD x 82.53mm L
BEARING, ball
2шт.
7
469372R1
DISC,13"
DISK, 13 in.
2шт.
180077
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
SCREW, 5/16-18 x 3/4 znd hex-hd cap
12шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
12шт.
120376
NUT,5/16"-18, G5
12шт.
8
480679R1
WASHER
dirt seal felt
2шт.
9
58194C1
ANGLE
PIVOT ASSY, marker LH
1шт.
9
58195C1
ANGLE
PIVOT ASSY, marker RH
1шт.
271771
HOUSING,Hex, 3/4" - 10 x 2", Gr 5
SCREW, 3/4-10 x 2 znd hex-hd cap
4шт.
87403
BOLT,Hex, 3/4" - 10 x 2 1/4", Gr 5
2шт.
87340
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
WASHER, LOCK, 3/4"
6шт.
10
548078R2
ARM
marker lift LH
1шт.
10
548079R2
ARM
marker lift RH
1шт.
19077R1
CARRIAGE BOLT,#3, 1/2" - 13 x 3", Gr 2
BOLT, 1/2 x 3 no. 3 repair plow
2шт.
11
468286R1
HEADED PIN,12.7mm OD x 92.08mm L
PIN, 1/2 x 3-7/16 C-Z std-hd
2шт.
12
520175R1
CLIP
PIN, 3/16 quick attachable cot.
4шт.
13
548747R1
ROD
marker disk clamp
2шт.
14
493944R2
TUBE
frame
4шт.
15
548077R1
ARM
marker pivot
2шт.
180185
BOLT,Hex, 1/2" - 13 x 2 1/2", Gr 5
SCREW, 1/2-13 x 2-1/2 znd hex-hd cap
4шт.
180188
BOLT,Hex, 1/2" - 13 x 2 3/4", Gr 5
SCREW, 1/2-13 x 2-3/4 znd hex-hd cap
6шт.
120384
WASHER,1/2"
LOCK, 1/2"
12шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
12шт.
16
493945R1
BRACE
frame
2шт.
113-257
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5
SCREW, 3/8-16 x 2-1/2 znd hex-hd cap
8шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
8шт.
120377
NUT,3/8" - 16, Gr 5
8шт.
17
493982R2
BUSHING
pivot
4шт.
413-1036
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
SCREW, 5/8-11 x 2-1/4 znd hex-hd cap
4шт.
464623R1
WASHER
21/32 x 1-1/2 x 11 ga C-Z
4шт.
492-11062
BEARING WASHER,5/8"
WASHER, LOCK, 5/8"
4шт.
231-14410
NUT,5/8"-11, GB
NUT, LOCK, 5/8"-11, GB
4шт.
18
489758R2
PIPE
ASSY
2шт.
20314R1
BOLT,Short NK, 1/2"-13 x 2 1/2", G2
1/2 x 2-1/2 znd sq-nk crg
6шт.
18710R1
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 3", Gr 2
BOLT, 1/2 x 3 znd sq-nk crg
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
8шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
8шт.
19
489774R3
PULLEY
ASSY, LH
1шт.
19
489775R3
PULLEY
ASSY, RH
1шт.
21761R1
WASHER
29/32 x 1-1/2 x 16 ga C-Z
6шт.
20340R1
COTTER PIN,1/4" x 1 1/2"
PIN, SPLIT (COTTER), 1/4" x 1 1/2"
2шт.
20
58302C1
TUBE ASSY 22" Length
2шт.
21
493951R1
ROD
marker brace
2шт.
21782R1
WASHER
21/32 x 1-1/2 x 16 ga C-Z
2шт.
187988
COTTER PIN,3/16" x 1 1/4"
PIN, SPLIT (COTTER), 3/16" x 1 1/4"
2шт.
22
493952R1
CHAIN (AG)
CHAIN, actuator
2шт.
18656R1
BOLT,Hex, 1/4" - 20 x 1 1/4", Gr 2
1/4 x 1-1/4 znd hex-hd mach
2шт.
20600R1
WASHER
9/32 x 1 x 18 ga C-Z
2шт.
480891R1
NUT
1/4-20 C-Z hex. flange lock
2шт.
23
22090R1
HEADED PIN
PIN, 3/4 x 7/8 C-Z std-hd
2шт.
24
548076R1
LINK
BRACKET, outer end pivot
2шт.
21341R1
HEADED PIN,1/2" x 1"
PIN, 1/2 x 1 znd std-hd
2шт.
18481R1
COTTER PIN,3/16" x 1"
PIN, SPLIT (COTTER), 3/16" x 1"
2шт.
25
493959R1
BLOCK
STOP, marker frame
2шт.
180124
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
SCREW, 3/8-16 x 1-1/4 znd hex-hd cap
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
26
493962R2
CLAMP, hyd hose
4шт.
18822R1
BOLT,Hex, 5/8"-11 x 1 1/2", G2, Full Thd
5/8 x 1-1/2 znd hex-hd mach
4шт.
492-11062
BEARING WASHER,5/8"
WASHER, LOCK, 5/8"
4шт.
27
548207R93
CYLINDER ASSY.
CYLINDER ASSY, 2 x 8 in. single acting hydraulic, order cylinder assy, 145622C91, for components see list of parts under details of hyd cylinder
2шт.
22964R1
HEADED PIN,1" x 2 7/16"
PIN, 1 x 2-7/16 zn std-hd
4шт.
520175R1
CLIP
PIN, 3/16 quick attachable cot.
4шт.
28
113118C91
BRACKET w/PRODUCT GRAPHIC, 113116C1, marker warning
2шт.
413-432
SCREW, 1/4-20 x 2 znd hex-hd cap
4шт.
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
4шт.
120375
NUT,Hex, 1/4" - 20, Gr 5
4шт.
Выбрано товаров: 79
