Запчасти Case IH 2150 (35.744.AD[07]) - HYDRAULIC DOWN PRESSURE DELTA FORCE VALVE, 24 ROW (35) - HYDRAULIC SYSTEMS

1

47794274

VALVE PRESSURE RELIE

Delta Force, 24 Row

1шт.

2

47797848

TUBE

Delta Force, Supply, 600mm L

1шт.

3

47797850

TUBE

Delta Force, Return, 516mm L

1шт.

4

47918955

HYD TUBE

Lift Fold Valve, 1626mm L, Incl 24

2шт.

5

47797954

HYDRAULIC HOSE

1605mm L, Incl 24, 25

1шт.

6

47797955

HYDRAULIC HOSE

1145mm L, Incl 24, 25

1шт.

7

47797956

HYDRAULIC HOSE

1165mm L, Incl 24

1шт.

8

47797957

HYDRAULIC HOSE

1625mm L, Incl 24

1шт.

9

87672176

HYD CONNECTOR

8шт.

10

87610720

HYD CONNECTOR,7/8" - 14 ORB x 13/16" - 16 ORFS

1шт.

11

83962539

HYD CONNECTOR,1" - 14 ORFS x 1-1/16 - 12 ORB

1шт.

12

84390792

90 ELBOW

1шт.

13

86591334

TEE,11/16"-16 ORFS x 11/16"-16 Fem

3шт.

14

86639080

TEE,13/16"-16 ORFS, Blkd Run

1шт.

15

86639081

TEE,1"-14 ORFS, Bulkhead

1шт.

16

86639083

BHD LOCK NUT,13/16"-16 ORFS, Bulkhead

1шт.

17

86639085

BHD LOCK NUT,1"-14, Bulkhead

3шт.

18

86050279

FLANGE NUT,M10 x 1.5, Cl 10

3шт.

19

87000140

CLAMP,Tube, 19.05mm

2шт.

20

87000230

PLATE

2шт.

21

300807

BOLT,Hex, M8 x 140, 8.8

2шт.

22

86619801

FLANGE NUT,M8 x 1.25, Cl 8

2шт.

23

87681213

BOLT,Hex, M10 x 140mm, Cl 10.9

3шт.

24

9992069

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

5шт.

25

9992298

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

2шт.
