Запчасти Case IH 1200PT (A.10.A[36]) - LAYOUT HYD HOSES ROUTING 12/23 ROW (ASN CBJ026003) A - Distribution Systems

Схема запчастей Case IH 1200PT - (A.10.A[36]) - LAYOUT HYD HOSES ROUTING 12/23 ROW (ASN CBJ026003) A - Distribution Systems
25
4
29
39
34
28
33
24
34
44
36
4
7
42
31
6
6
7
6
26
8
1
18
29
17
16
7
39
28
5
6
5
31
31
32
20
15
6
28
5
38
7
12
24
19
6
4
4
24
15
13
4
4
4
37
27
16
7
41
6
5
3
25
11
22
8
4
21
24
34
7
5
30
43
27
4
7
28
15
16
23
3
6
40
6
5
14
23
5
26
5
4
4
25
25
2
5
7

Артикул

Название

Примечание

Количество

1

87439659

CONTROL VALVE

assembly, multi-valve with plugs

1шт.

2

417538A1

CONTROL VALVE

assembly multi with relief

1шт.

3

87447161

BRACKET

hose routing

2шт.

Used with "Marker" Option

1шт.

4

427781A1

HOSE CLAMP

2 hose

11шт.

Used with "Marker" Option

1шт.

4

427781A1

HOSE CLAMP

2 hose

2шт.

Used with "No Marker" Option

1шт.

5

86512176

BOLT,Hex Flg, 3/8" - 16 x 2", Gr 5

9шт.

6

86594406

CLAMP,15.9mm, Coat, 10.3mm Bolt Hole, P Type

10шт.

7

76350

HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC

9шт.

8

86629586

90 ELBOW,9/16" - 18 JIC x 9/16" - 18 Fem Sw

2шт.

9

87454632

HYDRAULIC HOSE

5/8" x 525" fl

1шт.

10

87454635

HYDRAULIC HOSE

3/4" x 520" fl

1шт.

11

1284296C1

HYDRAULIC HOSE,9.52 mm ID x 1905.00 mm

1шт.

12

1284296C1

HYDRAULIC HOSE,9.52 mm ID x 1905.00 mm

1шт.

13

1259625C1

HYDRAULIC HOSE,9.50 mm ID x 840.00 mm, SAE 100R1

1шт.

14

1259625C1

HYDRAULIC HOSE,9.50 mm ID x 840.00 mm, SAE 100R1

1шт.

15

87454633

HYDRAULIC HOSE

5/8" x 190" fl

1шт.

16

87454636

HYDRAULIC HOSE

3/4" x 188" fl

1шт.

17

1259625C1

HYDRAULIC HOSE,9.50 mm ID x 840.00 mm, SAE 100R1

1шт.

18

1259625C1

HYDRAULIC HOSE,9.50 mm ID x 840.00 mm, SAE 100R1

1шт.

19

1284296C1

HYDRAULIC HOSE,9.52 mm ID x 1905.00 mm

1шт.

20

1284296C1

HYDRAULIC HOSE,9.52 mm ID x 1905.00 mm

1шт.

21

87447338

HARNESS

frame

1шт.

22

398135A1

WIRE HARNESS

toolbar 4 sections

1шт.

23

87446922

PLATE

hydraulic hose routing

2шт.

Used with "Marker" Option

1шт.

24

86511443

BOLT,Hex Serr, 1/4" - 20 x 1", 5SPL, Full Thd

4шт.

Used with "Marker" Option

1шт.

25

86625061

NUT,1/4"-20, GB

4шт.

Used with "Marker" Option

1шт.

26

86512175

BOLT,Hex Serr Flg, 3/8" - 16 x 1 1/2"

2шт.

Used with "Marker" Option

1шт.

27

247780

SERRATED NUT,Flg, USR, 3/8"-16

2шт.

Used with "Marker" Option

1шт.

28

529070

CABLE TIE,368.3mm L

CABLE STRAP

4шт.

Used with "Marker" Option

1шт.

29

87454634

HYDRAULIC HOSE

3/4" x 70" fl

1шт.

30

90879C1

HYDRAULIC HOSE,12.70 mm ID x 2030.00 mm, SAE 100R1

1шт.

31

133933C2

HYDRAULIC HOSE

3/8" x 260" fl

1шт.

32

301277A1

HYDRAULIC HOSE,19.05mm ID x 2540mm L

3/4" x 90" fl

1шт.

33

90879C1

HYDRAULIC HOSE,12.70 mm ID x 2030.00 mm, SAE 100R1

1шт.

34

1284369C1

HYDRAULIC HOSE

3/8" x 130" fl

1шт.

36

401592A1

VALVE, CONTROL

assembly marker

1шт.

37

128830

90 ELBOW,3/4" - 16 JIC x 3/4" - 16 ORB

2шт.

38

410538A1

HYDRAULIC HOSE

5/8" x 94" fl

1шт.

39

410538A1

HYDRAULIC HOSE

5/8" x 94" fl

1шт.

40

91204C1

HYDRAULIC HOSE,12.7mm ID x 4320mm L

1шт.

41

90874C1

HYDRAULIC HOSE

1/2" x 55" fl

1шт.

42

87557087

CABLE TIE

CABLE STRAP 11" with stainless locking clip

1шт.

43

87557087

CABLE TIE

CABLE STRAP 11" with stainless locking clip

1шт.

44

87454631

HYDRAULIC HOSE

5/8" x 77" fl

1шт.

Выбрано товаров: 53
