Запчасти Case IH 1200PT (F.10.G[04]) - LAYOUT TAKE UP CARRIER HOSE ROUTING 16/31 ROW (BSN CBJ0011170) F - Frame Positioning

1

86513087

FITTING,Blkhd, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree

4шт.

2

9610690

FITTING,Blkhd, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree

5шт.

3

86508629

FITTING,Blkhd, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree

3шт.

4

595460

BHD LOCK NUT,7/8" - 14

5шт.

5

86525

LOCK NUT,Blkhd, 9/16"-18

4шт.

6

86513143

BHD LOCK NUT,Blkhd, 1 1/16"-12

3шт.

7

86512959

45 ELBOW,45 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw

1шт.

8

86512960

ELBOW,45 Degree, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree Fem Sw

1шт.

9

219605

ELBOW,45 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw

1шт.

10

129274

TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC

1шт.

11

86629586

90 ELBOW,9/16" - 18 JIC x 9/16" - 18 Fem Sw

1шт.

12

427941A4

SUPPORT

hose holder

1шт.

15

444333A1

BRACKET

hose holder

2шт.

16

515-23317

CLAMP,31.75mm ID, 10.3mm Bolt Hole, P Type

5шт.

17

86505980

BOLT,Hex, 3/8" - 16 x 4 1/2", Gr 5

4шт.

18

247780

SERRATED NUT,Flg, USR, 3/8"-16

7шт.

19

444317A1

CLAMP

4 hoses

6шт.

20

9827902

CLAMP,25.4mm, Coat, 10.3mm Bolt Hole, P Type

3шт.

21

84192885

BOLT

Hex, 3/8"-16 x 3 3/4", G5

2шт.

22

80012047

BOLT,Hex, 3/8" - 16 x 4", Grade 5

1шт.

23

193225A1

HYDRAULIC HOSE

3/8" x 325" fl

1шт.

24

193225A1

HYDRAULIC HOSE

3/8" x 325" fl

1шт.

25

410542A1

HYDRAULIC HOSE

3/4" x 432" fl

1шт.

26

410542A1

HYDRAULIC HOSE

3/4" x 432" fl

1шт.

27

410534A1

HYDRAULIC HOSE,16mm ID x 10980mm L, SAE 100R17

5/8" x 432" fl

1шт.

28

410534A1

HYDRAULIC HOSE,16mm ID x 10980mm L, SAE 100R17

5/8" x 432" fl

1шт.

29

1284268C1

HYDRAULIC HOSE

3/8" x 340" fl

1шт.

30

1284268C1

HYDRAULIC HOSE

3/8" x 340" fl

1шт.

31

410534A1

HYDRAULIC HOSE,16mm ID x 10980mm L, SAE 100R17

5/8" x 432" fl

1шт.

32

426732A1

HYDRAULIC HOSE,19mm ID x 9400mm L

3/4" x 370" fl

1шт.

33

426728A1

HYDRAULIC HOSE,16mm ID x 10300mm L

5/8" x 405" fl

1шт.

34

410534A1

HYDRAULIC HOSE,16mm ID x 10980mm L, SAE 100R17

5/8" x 432" fl

1шт.

35

398137A1

HARNESS

40' power

1шт.

16 row and 16/31 row planters

1шт.

36

76355

TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC

1шт.

37

86629586

90 ELBOW,9/16" - 18 JIC x 9/16" - 18 Fem Sw

1шт.

38

86984798

TAG

warning, case drain

1шт.

38

87527165

WARNING DECAL

Case Drain French

1шт.

39

218-736

UNION,7/8"-14, 37 Degree x 7/8"-14, 37 Degree

1шт.

40

144121

UNION,1-1/16" - 12 JIC x 1-1/16" - 12 JIC

1шт.

41

128817

HYD CONNECTOR,3/4" - 16 ORB x 9/16" - 18 JIC

1шт.

Includes O-Ring

1шт.

42

85999239

QUICK MALE COUPLING,3/8" x 3/4" - 16 ORB

stl 3/8"

1шт.

43

1284367C1

HYDRAULIC HOSE,9.53mm ID x 2415mm L

3/8" x 95" fl

1шт.

44

451592A1

HOSE,16mm ID x 680mm L

extension press

1шт.

45

451593A1

HOSE,19mm ID x 1580mm L, SAE 100R17

extension return

1шт.

46

144124

HYD CONNECTOR,1-1/16" - 12 JIC x 7/8" - 14 ORB

3шт.

Includes O-Ring

1шт.

47

87301330

HYD CONNECTOR,7/8" - 14 ORB x 7/8" - 14 JIC

5/8" mb x 5/8" mj

5шт.

Includes O-Ring

1шт.

48

1272399C2

QUICK MALE COUPLING

self sealing, 7/8" NF

8шт.

49

333719A1

CAP

hydraulic quick coupler female, yellow

2шт.

50

333722A1

CAP

female quick coupler green

2шт.

51

333717A1

CAP

female qc blue

2шт.

52

333721A1

CAP

female quick coupler red

2шт.

53

128825

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1шт.

54

167269

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

a

812381C2

HYDRAULIC HOSE

3/8" x 115" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

a

193225A1

HYDRAULIC HOSE

3/8" x 325" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

b

129671C2

HYDRAULIC HOSE

3/8" x 105" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

b

193225A1

HYDRAULIC HOSE

3/8" x 325" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

c

410535A2

HYDRAULIC HOSE

5/8" x 119" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

c

410534A1

HYDRAULIC HOSE,16mm ID x 10980mm L, SAE 100R17

5/8" x 432" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

c

333721A1

CAP

female quick coupler red

1шт.

d

410536A2

HYDRAULIC HOSE

5/8" x 114" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

d

410534A1

HYDRAULIC HOSE,16mm ID x 10980mm L, SAE 100R17

5/8" x 432" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

d

333721A1

CAP

female quick coupler red

1шт.

e

139519C2

HYDRAULIC HOSE

3/8" x 135" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

e

1284292C1

HYDRAULIC HOSE

3/8" x 245" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

e

1284268C1

HYDRAULIC HOSE

3/8" x 340" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

e & h

1284367C1

HYDRAULIC HOSE,9.53mm ID x 2415mm L

3/8" x 95" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

f

87424845

HYDRAULIC HOSE

5/8" x 180" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

f

410534A1

HYDRAULIC HOSE,16mm ID x 10980mm L, SAE 100R17

5/8" x 432" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

f

333722A1

CAP

female quick coupler green

1шт.

g

87424846

HYDRAULIC HOSE

3/4" x 182" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

g

410542A1

HYDRAULIC HOSE

3/4" x 432" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

g

333722A1

CAP

female quick coupler green

1шт.

h

1284292C1

HYDRAULIC HOSE

3/8" x 245" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

h

1284268C1

HYDRAULIC HOSE

3/8" x 340" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

i

426726A1

HYDRAULIC HOSE,16.00 mm ID x 3450.00 mm, SAE 100R17

5/8" x 135" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

i

410534A1

HYDRAULIC HOSE,16mm ID x 10980mm L, SAE 100R17

5/8" x 432" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

i

333719A1

CAP

hydraulic quick coupler female, yellow

1шт.

j

426725A1

HYDRAULIC HOSE,19.00 mm ID x 3450.00 mm, SAE 100R17

3/4" x 135" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

j

410542A1

HYDRAULIC HOSE

3/4" x 432" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

j

333719A1

CAP

hydraulic quick coupler female, yellow

1шт.

m

451579A1

HYDRAULIC HOSE

5/8" x 300" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

m

426728A1

HYDRAULIC HOSE,16mm ID x 10300mm L

5/8" x 405" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

m

451592A1

HOSE,16mm ID x 680mm L

extension press

1шт.

Hoses from bulkhead to front of planter

1шт.

m

333717A1

CAP

female qc blue

1шт.

n

451580A1

HYDRAULIC HOSE

3/4" x 300" fl

1шт.

Hoses from planter to back of bulkhead

1шт.

n

426732A1

HYDRAULIC HOSE,19mm ID x 9400mm L

3/4" x 370" fl

1шт.

Hoses from bulkhead to front of planter

1шт.

n

451593A1

HOSE,19mm ID x 1580mm L, SAE 100R17

extension return

1шт.

Hoses from bulkhead to front of planter

1шт.

n

333717A1

CAP

female qc blue

1шт.

w

398137A1

HARNESS

40' power

1шт.

16 row and 16/31 row planters

1шт.
