Запчасти Case IH 1200 (L.40.A[19]) - LIQUID FERTILIZER SQUEEZE PUMP ASSEMBLY, 6 & 8 ROW RIGID TRAILING (BSN CBJ0018110) L - Field Processing

Схема запчастей Case IH 1200 - (L.40.A[19]) - LIQUID FERTILIZER SQUEEZE PUMP ASSEMBLY, 6 & 8 ROW RIGID TRAILING (BSN CBJ0018110) L - Field Processing
8
23
15
38
41
44
46
34
24
14
4
2
60
18
26
45
7
63
28
43
21
17
59
53
57
13
48
47
27
9
6
36
58
61
31
56
25
32
32
15
51
35
30
40
50
20
57
55
27
3
14
46
29
49
1
5
42
39
19
54
4
33
22
56
16
10
11
52
6
12
5
37

Артикул

Название

Примечание

Количество

0

416826A1

PUMP

6 row liquid fertilizer squeeze

1шт.

6 Row

1шт.

0

416825A1

PUMP

8 row liquid fertilizer squeeze

1шт.

8 Row

1шт.

1

416829A1

FRAME ASSY

main, 6 row

1шт.

6 Row

1шт.

1

416838A1

FRAME

main, 8 row

1шт.

8 Row

1шт.

2

416830A1

PLATE

side LH

1шт.

3

416831A1

PLATE

side RH

1шт.

4

87872

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

10шт.

5

80681

LOCK WASHER,5/16"

10шт.

6

9635082

NUT,5/16" - 18, Gr 5

10шт.

7

416837A1

LID

channel, pump

1шт.

7

416836A1

LID

channel, 8 row pump

1шт.

8

86624096

COTTER PIN,Int, 3/16 x .080"

2шт.

9

64690C1

ANGLE

lever bracket

1шт.

10

9707580

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd

2шт.

11

80682

LOCK WASHER,1/4"

2шт.

12

7770

NUT,Hex, 1/4 - 20, Cl 5

2шт.

13

64692C1

SUPPORT

adjuster lever

1шт.

14

86511938

SCREW,Pan, 5/16" - 18 x 3/4"

2шт.

15

9635082

NUT,5/16" - 18, Gr 5

2шт.

16

64691C1

ANGLE

lever tightener

1шт.

17

80299

WASHER,0.69" ID x 1.75" OD x 0.13" Thk

4шт.

18

325-159

JAM NUT,Jam, 9/16"-18, G5

4шт.

19

1261290C1

ROLLER

pump shaft - short

4шт.

6 Row

1шт.

19

1261303C1

ROLLER

pump shaft, short

4шт.

8 Row

1шт.

20

1261291C1

ROLLER

pump shaft - long

4шт.

6 Row

1шт.

20

1261302C1

ROLLER

pump shaft, long

4шт.

8 Row

1шт.

21

1261287C1

ROD

shaft, pump drive

1шт.

6 Row

1шт.

21

1261288C1

ROD

shaft pump drive

1шт.

8 Row

1шт.

22

64693C1

HOSE,0.50" ID x 21.50"

Neoprene Rubber

1шт.

22

134283C1

HOSE,0.38" ID x 21.50"

Neoprene Rubber

1шт.

22

134284C1

HOSE

5/8" x 21 1/2" neoprene rubber

1шт.

23

134276C1

CLAMP

hose ss SAE #11 for 1/2"

1шт.

23

134277C1

CLAMP

hose ss SAE #9 for 3/8"

1шт.

23

134278C1

CLAMP

hose ss SAE #12 for 5/8"

1шт.

24

416828A1

WHEEL

cylinder

1шт.

25

84983

SET SCREW,3/8" x 1"

2шт.

26

87016560

JAM NUT,Jam, 3/8"-16, G5

2шт.

27

142694

FLANGED BEARING

3 hole

4шт.

28

455958R11

COLLAR,19.05mm ID x 32.94mm OD x 13.49mm W

bearing lock 3/4" with set screw

2шт.

29

455957R92

BEARING ASSY,19.05mm ID x 47mm OD x 14mm W

3/4" bore

2шт.

30

472344R3

SPROCKET

idler

3шт.

31

87972

BOLT,Hex, 1/2" - 13 x 2 1/2", Gr 5

3шт.

32

80299

WASHER,0.69" ID x 1.75" OD x 0.13" Thk

4шт.

33

80679

LOCK WASHER,1/20.507 CST ZND

3шт.

If used

1шт.

34

86992215

LOCK NUT,1/2"-13, GC

3шт.

35

86632558

JAM NUT,Jam, 1/2"-13, G5

3шт.

36

416827A1

FRONT PLATE

1шт.

6 Row

1шт.

36

416835A1

FRONT PLATE

8 row

1шт.

8 Row

1шт.

37

86505867

BOLT,Hex, 1/4" - 20 x 1", Gr 5

4шт.

38

80682

LOCK WASHER,1/4"

4шт.

39

7770

NUT,Hex, 1/4 - 20, Cl 5

4шт.

40

234726

CLEVIS PIN,6.29mm OD x 20mm L

1шт.

41

86624096

COTTER PIN,Int, 3/16 x .080"

1шт.

42

1261298C1

BRACKET

tightener holder

1шт.

43

9707580

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd

2шт.

44

80682

LOCK WASHER,1/4"

2шт.

45

7770

NUT,Hex, 1/4 - 20, Cl 5

2шт.

46

64698C1

THRUST WASHER

thrust, 12 gauge

1шт.

47

64699C1

SPRING

C 1 1/8" od

1шт.

48

1261268C2

MANIFOLD

metering pump

1шт.

6 Row

1шт.

48

1261304C2

MANIFOLD

metering pump

1шт.

8 Row

1шт.

49

64696C1

PLUG

poly 1/2" mp hex head

2шт.

6 Row

1шт.

50

64695C1

FITTING

nylon straight adapter 1/2" mpt x 1/2" hb

1шт.

50

134274C1

FITTING

nylon straight 1/2" mpt x 3/8" hb

1шт.

50

134275C1

FITTING

nylon straight 1/2" mpt x 5/8" hb

1шт.

51

64694C1

FITTING

nylon straight 1/2" hb x 1/2" hb

1шт.

51

134280C1

FITTING

nylon straight 1/2" hb x 3/8" hb

1шт.

51

134281C1

FITTING

nylon straight 1/2" hb x 5/8" hb

1шт.

52

416839A1

CLAMP

pump manifold

2шт.

53

416832A1

CLIP

long, mounting

1шт.

54

416833A1

CLIP

short, mounting

1шт.

55

9637417

BOLT,Hex, 1/2" - 13 x 3 1/2", Gr 5

1шт.

56

80679

LOCK WASHER,1/20.507 CST ZND

1шт.

57

280431

NUT,1/2"-13, G5

1шт.

58

416834A1

GUARD

hose

1шт.

8 Row

1шт.

59

134271C2

ELBOW,ELBOW, 90

poly 90º 3/4" mpt x 1" hb

2шт.

60

134278C1

CLAMP

hose ss SAE #12 for 5/8"

1шт.

61

86624007

HOSE CLAMP,#20, 1 1/4", Spring

1шт.

62

1254279C1

DECAL,Chart Output In Gallon Per Acre

liquid fertilizer output in gal

1шт.

Not Shown

1шт.

63

87689

BOLT,1/2"-13 x 1.813" OAL, Gr 5

1шт.

Выбрано товаров: 98
