Запчасти Case IH 1200 (A.10.A[16]) - FAN HYDRAULICS - RIGID TRAILING (VARIABLE RATE) - DETAILS B AND C A - Distribution Systems

1

87427490

VALVE

assembly multi with plugs

1шт.

3

91205C1

HYDRAULIC HOSE,12.70 mm ID x 5335.00 mm, SAE 100R1

1шт.

5

135368A1

HYDRAULIC HOSE

3/4" x 200" (5080 mm) fl

1шт.

7

87421376

BRACKET

valve mount

1шт.

8

87506450

QUICK MALE COUPLING

1/2"m-tip x 1/2" fb poppet style

2шт.

9

1330108CX

SEAL,304.8mm L

Trim Edge Black, 250' Roll, Serial Range: -CBJ022936

1шт.

9

87502709

PROTECTIVE SLEEVE,2-1/2" OD x 18" L

2 1/2" x 18" hyd hose protector, Start Serial: CBJ022937

1шт.

10

87433237

SHIELD

multi-valve

1шт.

11

1250813C1

U-BOLT

us 5/8"-11 x 7" x 8 1/4", G5, 2" thread

2шт.

12

85999239

QUICK MALE COUPLING,3/8" x 3/4" - 16 ORB

stl 3/8"

1шт.

13

280374

NUT,Hex, 5/8" - 11, Gr 5

4шт.

14

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3шт.

15

80680

LOCK WASHER,3/8 0.381 CST ZND

3шт.

16

12034871

WASHER

5/8"

4шт.

17

128818

UNION,3/4" - 16 ORB x 3/4" - 16 JIC

1шт.

18

128819

HYD CONNECTOR,7/8" - 14 ORB x 3/4" - 16 JIC

2шт.

19

577993

HYD CONNECTOR,1-1/16" - 12 JIC x 3/4" - 16 ORB

1шт.

20

322896

HYD CONNECTOR,1-1/16" - 12 ORB x 1-1/16" - 12 JIC

2шт.

21

128817

HYD CONNECTOR,3/4" - 16 ORB x 9/16" - 18 JIC

1шт.

22

86984798

TAG

warning, case drain

1шт.

22

87527165

WARNING DECAL

Case Drain French

1шт.

23

86627130

WING NUT,1/4"-20

2шт.
