Запчасти Case IH 1200 (D.13.B[21]) - DRIVE SYSTEM - MOUNTED STACKER, 3 SHAFT TRANSMISSION (BSN CBJ036000) D - Travel

1

1277925C92

RATCHET

23 tooth LH

1шт.

2

1277926C92

RATCHET

23 tooth RH

1шт.

9

402950A1

DRIVE SHAFT

hex, 7/8" x 2440 mm

4шт.

12 Row Narrow

1шт.

36" Spacing

1шт.

10

402954A1

DRIVE SHAFT

7/8" hex x 2010 mm

5шт.

12 Row Narrow

1шт.

10a

90560C1

SHAFT

Drive, Hex, 22 (7/8) x 1360 mm (53-35/64 inch) Long

2шт.

8 Row Wide

1шт.

36" Spacing

1шт.

10a

402953A1

DRIVE SHAFT

hex, 7/8" x 1750 mm

2шт.

8 Row Wide

1шт.

10a

402953A1

DRIVE SHAFT

hex, 7/8" x 1750 mm

2шт.

8 Row Wide

1шт.

38 & 40" Spacing

1шт.

10b

402955A1

DRIVE SHAFT

7/8" hex x 2660 mm

2шт.

8 Row Wide

1шт.

10b

402955A1

DRIVE SHAFT

7/8" hex x 2660 mm

1шт.

12 Row Wide

1шт.

36" Spacing

1шт.

10b

402955A1

DRIVE SHAFT

7/8" hex x 2660 mm

5шт.

12 Row Wide

1шт.

38 & 40" Spacing

1шт.

11

402451A1

SHAFT

hex, 7/8" x 13 15/16" with 2 holes

1шт.

13

87404

BOLT,Hex, 1/4" - 20 x 2", Gr 5

4шт.

14

280129

NUT,1/4"-20

4шт.

15

400583A1

COUPLING,22.48mm ID x 38.1mm OD x 70mm L

seed drive

2шт.

16

86624123

SET SCREW,Hex Skt, 1/2" - 13 x 1/2"

36шт.

17

1277812C3

SPACER

double sprocket

2шт.

18

87461085

SPROCKET

collar locking

10шт.

19

1277739C91

CHAIN (AG)

primary wheel drive, no. 2050, use 45 links from 569089R91 bulk chain and (1) 1277928C91 connecting link

2шт.

19

569089R91

CHAIN (AG),10' L, 1.0" Pitch

#2050 - 10' d/p roller

1шт.

19

1277928C91

LINK

connecting #2050

1шт.
