Запчасти Case IH 10 (D-03) - HOPPER LID AND COVER

1

607280R91

COVER, grain hopper

1шт.

2

603026R1

HINGE

grain hopper cover

4шт.

440-12510

SCREW,Cross Pan Hd, 1/4"-20 x 5/8"

1/4 X 5/8" SLT-RD-HD SCREW

8шт.

109084

NUT,1/4"-20, G5

8шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK 1/4"

8шт.

3

607270R1

COVER, fertilizer hopper

1шт.

4

N11662

HINGE, fertilizer hopper cover

5шт.

440-1258

SCREW,Cross Pan Hd, 1/4"-20 x 1/2"

1/4 X 1/2" SLT-RD-HD SCREW

10шт.

109084

NUT,1/4"-20, G5

10шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK 1/4"

10шт.

5

607225R91

SUPPORT, cover

1шт.

20893R1

WASHER

11/32 X 1 X 11 GA C-Z WASHER

1шт.

120376

NUT,5/16"-18, G5

2шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.
