Запчасти Case IH 66-SERIES (U-60) - CORN PLANTING EQUIPMENT, FOR COMBINATION HOPPER, 1966

Схема запчастей Case IH 66-SERIES - (U-60) - CORN PLANTING EQUIPMENT, FOR COMBINATION HOPPER, 1966
3
16
7
6
1
14
11
13
15
4
10
5
2
9
8
12

Артикул

Название

Примечание

Количество

1

622184R91

PAWL

PAIR OF CUT-OFF PAWLS, inner & outer

1шт.

1

622278R91

JAW

PAIR OF CUT-OFF PAWLS, inner & outer, for use w/segmented or decorticated beet seed plates special

1шт.

2

2000AA

PIN

hinged cut-off pawl

1шт.

3

621727R3

CAP

cut-off and knocker

1шт.

16897R1

CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd

BOLT, 5/16 x 3/4 C-Z sq-nk crg

1шт.

120376

NUT,5/16"-18, G5

1шт.

4

621728R2

SEAT

adjusting knocker

1шт.

85700996

SCREW,Phillips Drive, Pan HD, 1/4" - 20 x 1/2"

1/4 x 1/2 slt-rd-hd mach

1шт.

120392

WASHER,1/4", SAE

9/32 x 5/8 x .065 C-Z

1шт.

5

2064A

SPRING

cut-off and knocker

3шт.

6

464336R11

KNOCKER

ARM ASSEMBLY, roller knocker

1шт.

7

622124R3

HOLDER

RETAINER, filler ring

1шт.

133781

SCREW,Sl Flat Hd, 1/4" - 20 x 1 1/4"

1/4-20 x 1-1/4 C-Z slt-f-hd

1шт.

120375

NUT,Hex, 1/4" - 20, Gr 5

1шт.

138604

LOCK WASHER,Ext Csk Tooth, 1/4"

WASHER, 1/4 C-Z ext-tooth lock

1шт.

8

13607AB

HINGE

GATE, hinged

1шт.

9

BOTTOM, corn, order 480697R91

1шт.

10

480697R91

BOTTOM

complete corn

1шт.

11

PLATE, seed, see plate, section

1шт.

12

PLATE, filler, see seed plate, section

1шт.

13

3460AC

KNOCKER

regular, for sorghum, kaffir corn, maize, etc.

1шт.

14

1223AB

PAWL

KNOCKER, special, see note

1шт.

15

43169AA

ARM

COMPLETE W/STUD, roller knocker special, see note

1шт.

16

3616AA

KNOCKER

roller, for 82 cell plate, special, see note

1шт.

16

464259R1

ROLLER

KNOCKER, roller

1шт.

Выбрано товаров: 25
