Запчасти Case IH 188 (C-14) - DISK AND BLADE COVERS

Схема запчастей Case IH 188 - (C-14) - DISK AND BLADE COVERS
10
4
14
11
1
8
12
16
9
6
13
7
15
2
3
5

Артикул

Название

Примечание

Количество

1

478069R1

ANCHOR, pressure rod

4шт.

102635

NUT,3/8"-16, G5

2шт.

179847

BOLT,Hex, 3/8" - 16 x 2", Gr 5

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

2

477143R11

ROD

pressure

1шт.

2

468482R11

ROD, pressure, order 477143R11 and 477144R1

2шт.

102635

NUT,3/8"-16, G5

2шт.

13042R1

AXLE PIN,1/8" x 3/4"

Pin, Split (Cotter), , self-opening 1/8" x 3/4"

2шт.

CP14227

PIN

5/16 x 1-3/16 dld-std-hd

2шт.

20285H

WASHER

13/32 x 3/8 x 11 ga

4шт.

Q1504

WASHER

13/32 x 7/8 x 16 ga

4шт.

3

478068R91

BRACKET

ASSY, covering disk

2шт.

179883

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

2шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.

4

477144R1

SPRING

pressure rod

2шт.

5

471636R1

BRACKET, pivot

2шт.

15054R1

CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1 3/4", Gr 2

BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 3/4", G2

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

102635

NUT,3/8"-16, G5

1шт.

6

468483R2

ROD

STANDARD, covering disk

2шт.

7

468484R93

DISC

DISK

2шт.

7

468485R91

DISC

DISK, order (1) 517686R21, (1) 477550R1, and (6) 104083 rivets

1шт.

7

517686R21

NO LONGER SERVICED

DISK

2шт.

RIVET, 1/4 x 5/8 rd-hd

12шт.

8

SA6222

GASKET

2шт.

9

SA6228

BEARING

ball

2шт.

10

517687R2

BOLT,Carriage, 1/2" - 13 x 2 1/2"

1/2 x 2-1/2 sq-nk-dld crg

2шт.

102637

NUT,1/2"-13, G5

2шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.

16038R1

WASHER

17/32 x 1 x 11 ga

2шт.

11

125617

LUBE NIPPLE,3/16" x .61 lg, Drive

FITTING, 3/16 straight drive type lub.

2шт.

12

517685R1

RETAINER

HUB, bearing

2шт.

13

SA6219

RUBBER SEAL

dust

2шт.

14

517683R3

SUPPORT

2шт.

BOLT W/NUT, 1/2 x 1-3/4 crg

2шт.

15

468488R2

SCRAPER, covering disk RH

1шт.

15

468487R2

SCRAPER, covering disk LH

1шт.

16

477550R1

BAND, disk

2шт.

RIVET, 1/4 x 3/4 small b-hd

12шт.

Выбрано товаров: 39
