Артикул
Название
Примечание
Количество
1
488814R11
BOTTOM ASSY, combination hopper corn
1шт.
2
484871R91
SERVICE KIT
corn double pawl
1шт.
2
484884R91
COVER
ASSY, beet double pawl
1шт.
180697
SCREW, 5/16-24 x 2-1/8 C-Z hex-hd cap
1шт.
138538
LOCK WASHER
WASHER, 5/16 C-Z int-tooth lock
1шт.
124920
JAM NUT,Jam, 5/16"-24, G5
1шт.
3
484883R1
PIN
3/16 x 1 knurled hd, cutoff pawl pivot
1шт.
4
484882R1
PIN
3/16 x 1-1/2 knurled hd, knocker arm pivot
1шт.
5
20479R1
PIN, 3/16 x 1-1/4 C-Z champered str, cutoff pawl stop
1шт.
6
484875R1
PAWL
corn cutoff
2шт.
6
484874R1
PAWL
beet cutoff
2шт.
7
484885R11
ARM
assy, corn roller knocker
1шт.
7
484872R11
ARM
assy, beet roller knocker
1шт.
488808R1
SCREW
10 x 1/2 C-Z slt-pan-hd tap
1шт.
8
484881R1
SPRING
cutoff pawl and knocker
3шт.
9
484879R1
DOOR
GATE, double pawl cover
1шт.
10
488817R1
ANGLE, filler ring retainer
1шт.
18877R1
BOLT
1/4-20 x 1-1/4 C-Z sq-hd mach
1шт.
16559R1
WASHER,1/4"
17/64 x 5/8 x .036 C-Z
1шт.
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
1шт.
120375
NUT,Hex, 1/4" - 20, Gr 5
1шт.
11
484878R11
ARM
ASSY, small seed knocker
1шт.
436694
SCREW,Slotted Pan Hd, #8-32 x 7/16"
8-32 x 7/16 C-Z slt-pan-hd mach
1шт.
138530
LOCK WASHER,Int Tooth, #8
WASHER, LOCK, Int Tooth, #8
1шт.
120622
NUT,#8-32
1шт.
PLATE, seed, refer to seed plate section
1шт.
RING, filler, refer to seed plate section
1шт.
Выбрано товаров: 28
