Запчасти Case IH 955 (4-40) - HARNESS, AFS PLANTER, 12 ROW NARROW, 16 ROW NARROW AND 12/23 SRC (04) - ELECTRICAL SYSTEMS

1

323288A1

HARNESS

- Cyclo MCC, connects to 323444A1 on 12RN & 16RN or 323318A1 on 12/23SRC and to the (not illustrated) items below

1шт.

2

323444A1

HARNESS

- Cyclo Fertilizer, 12RN & 16RN, connects to the following (not illustrated) items

1шт.

2

323318A1

HARNESS

- Cyclo fertilizer, 12/23 only, connects to the following (not illustrated) items

1шт.

3

323322A1

HARNESS

- extension, connects to the following (not illustrated) items

1шт.

4

293807A2

BOARD, PRINTED CIRCU

MODULE - bin level gateway, harness connects to the following (not illustrated) items

4шт.

5

333054A1

SENSOR

- application rate, harness connects to the following (not illustrated) items

1шт.

6

1336005C3

SENSOR

- air pressure, hopper, harness connects to the following (not illustrated) items

1шт.

7

188105A1

SOLENOID

- without diode, 12 volt, DC, harness connects to the following (not illustrated) items

3шт.

8

323276A1

HARNESS

- main, 12RN and 16RN, and 12/23 SRC, harness connects to the following ( not illustrated) items

1шт.

8

323445A1

HARNESS

- main, 24RN only, harness connects to the following (not illustrated) items

1шт.
