Запчасти Case IH 900 (9-264) - LIQUID FERTILIZER SQUEEZE PUMP ASSEMBLY, CYCLO AIR & PLATE TRAILING ALL ROW SIZES (09) - CHASSIS/ATTACHMENTS

Схема запчастей Case IH 900 - (9-264) - LIQUID FERTILIZER SQUEEZE PUMP ASSEMBLY, CYCLO AIR & PLATE TRAILING ALL ROW SIZES (09) - CHASSIS/ATTACHMENTS
68
27
49
24
67
39
4
63
66
32
25
53
31
55
19
71
26
8
64
50
1
15
34
23
7
14
58
72
5
69
17
37
22
52
56
20
18
5
38
20
29
74
65
33
32
9
30
70
16
59
57
8
36
21
3
59
37
7
40
51
28
35
60
10
19
73

Артикул

Название

Примечание

Количество

1250764C93

PUMP

ASSEMBLY - squeeze (4, 6 and 8 row)

1шт.

1250763C93

PUMP

ASSEMBLY - squeeze (8 row)

1шт.

1

1261292C1

FRAME

- main (4, 6 and 12 row)

1шт.

1

1261308C1

FRAME

- main

1шт.

3

1261293C2

PLATE

- side, left-hand

1шт.

4

1261294C2

PLATE

- side, right-hand

1шт.

5

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

- hex, 5/16 NC x 3/4 inch

10шт.

7

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

10шт.

8

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC

10шт.

9

1261307C1

CHANNEL

COVER - pump (4, 6 and 12 row)

1шт.

9

1261306C1

CHANNEL

COVER - pump (8 row)

1шт.

10

136-159

HAIR PIN COTTER,Int, 3/16 x .080"

PIN, SPLIT (COTTER), Int, 3/16 x .080"

1шт.

14

64690C1

ANGLE

BRACKET - lever

1шт.

15

413-48

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

- hex, 1/4 NC x 1/2 inch

2шт.

16

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

17

425-104

NUT,1/4"-20, Cl 5

- hex, 1/4 inch NC

2шт.

18

64692C1

SUPPORT

BRACKET - tightener

1шт.

19

470-13112

SCREW,Slotted Pan Hd, 5/16"-18 x 3/4"

- machine, pan head slotted, 5/16 NC x 3/4 inch

2шт.

20

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC

2шт.

21

64691C1

ANGLE

BRACKET - tightener

1шт.

22

495-21069

WASHER,5/8"

- flat, 11/16 x 1-3/4 x 9/64 inch

4шт.

23

325-159

JAM NUT,Jam, 9/16"-18, G5

- hex, jam, 9/16 inch NF

4шт.

24

1261290C1

ROLLER

- pump shaft (4, 6 and 12 row)

1шт.

24

1261303C1

ROLLER

- pump shaft (8 row)

1шт.

25

1261291C1

ROLLER

- pump shaft (4, 6 and 12 row)

1шт.

25

1261302C1

ROLLER

- pump shaft (8 row)

1шт.

26

1261287C1

ROD

SHAFT - pump drive (4, 6 and 12 row)

1шт.

26

1261288C1

ROD

SHAFT - pump drive (8 row)

1шт.

27

64693C1

HOSE,0.50" ID x 21.50"

1шт.

27

134283C1

HOSE,0.38" ID x 21.50"

0.38" ID x 21.50"

1шт.

27

134284C1

HOSE

- 16 (5/8) ID x 546 mm (21-1/2 inch) long

1шт.

28

134276C1

CLAMP

- spring type (Used with 1/2 inch hose)

2шт.

28

134277C1

CLAMP

- spring type (Used with 3/8 inch hose)

2шт.

28

134278C1

CLAMP

- spring type (Used with 5/8 inch hose)

2шт.

29

1261289C1

WHEEL

CYLINDER - wheel

1шт.

30

485-13816

SET SCREW,Sq Hd, 3/8"-16 x 1"

SCREW - set, square head, 3/8 NC x 1 inch, cup point

1шт.

31

329-146

JAM NUT,Jam, 3/8"-16, G5

1шт.

32

455961R1

BEARING HOUSING,3.5625" OD x 0.3125"

FLANGE - bearing collar

2шт.

33

455958R11

COLLAR,19.05mm ID x 32.94mm OD x 13.49mm W

- lock, bearing (With set screw)

1шт.

34

455957R92

BEARING ASSY,19.05mm ID x 47mm OD x 14mm W

- ball

1шт.

35

472344R3

SPROCKET

- idler

3шт.

36

413-840

BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5

- hex, 1/2 NC x 2-1/2 inch

3шт.

37

496-21053

WASHER,17/32" x 1 1/16" x .134"

- flat, 17/32 x 1-1/16 x 1/8 inch, hardened

6шт.

38

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, 1/2"

3шт.

39

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex 1/2"-13, G5

3шт.

40

325-108

NUT,1/2"-13, G5

- hex, jam, 1/2 inch NC

3шт.

48

1261269C1

PLATE

- front (4, 6 and 12 row)

1шт.

48

1261305C1

PLATE

- front (8 row)

1шт.

49

413-416

BOLT,Hex, 1/4" - 20 x 1", Gr 5

- hex, 1/4 NC x 1 inch

4шт.

50

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

4шт.

51

425-104

NUT,1/4"-20, Cl 5

- hex, 1/4 inch NC

4шт.

52

427-4077

CLEVIS PIN,1/4" x .770"

PIN, CLEVIS, , Hardened 1/4" x .770"

1шт.

53

432-416

COTTER PIN,1/16" x 1"

1/16" x 1"

1шт.

55

1261298C1

BRACKET

- tightener

1шт.

56

326-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 8

2шт.

57

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

58

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC

2шт.

59

64698C1

THRUST WASHER

- plate spring

2шт.

60

64699C1

SPRING

- extension

1шт.

63

1261268C2

MANIFOLD

- pump (4, 6 and 12 row)

1шт.

63

1261304C2

MANIFOLD

- pump (8 row)

1шт.

64

64696C1

PLUG

- pump manifold (4, 6 and 12 row)

1шт.

65

64695C1

FITTING

CONNECTOR - barbed (Used with 1/2 inch hose)

1шт.

65

134274C1

FITTING

CONNECTOR - barbed (Used with 3/8 inch hose)

1шт.

65

134275C1

FITTING

CONNECTOR - barbed (Used with 5/8 inch hose)

1шт.

66

64694C1

FITTING

CONNECTOR - barbed, 1/2 x 1/2 inch

1шт.

66

134280C1

FITTING

CONNECTOR - barbed, 1/2 x 3/8 inch

1шт.

66

134281C1

FITTING

CONNECTOR - barbed, 1/2 x 5/8 inch

1шт.

67

64697C1

CLAMP

- manifold retaining

2шт.

68

1261295C2

PLATE

BRACKET - retaining

1шт.

69

1261296C2

PLATE

BRACKET - retaining

1шт.

70

413-856

BOLT,Hex, 1/2" - 13 x 3-1/2", Gr 5

- hex, 1/2 NC x 3-1/2 inch

1шт.

71

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, 1/2"

1шт.

72

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex 1/2"-13, G5

1шт.

73

1261297C1

SUPPORT

GUARD - hose

1шт.

74

134271C1

ELBOW

- 90 degree, 1 stem x 3/4 inch PT

1шт.

Выбрано товаров: 76
