Запчасти Case IH 900 (9-082) - SEED MODULE HOUSING, CYCLO AIR PLANTERS, ALL EXCEPT CORN/SOYBEAN SPECIAL (09) - CHASSIS/ATTACHMENTS

1

97760C2

SHEET

PANEL - module side, right-hand

1шт.

2

97759C1

SHEET

PANEL - module side, left-hand

1шт.

3

409-7816

BOLT,Hex Flg, 1/2" - 13 x 1", Spcl

- hex serrated flange, 1/2 NC x 1 inch

8шт.

4

231-5148

FLANGE NUT,Flg, USR, 1/2"-13

8шт.

5

1263874C1

PANEL

- access

1шт.

6

256873

BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd

8шт.

7

96183C1

NUT,J, Ret, 5/16"-18

- J-type, 5/16 inch NC

6шт.

8

1333871C2

SHEET

PANEL - module, rear

1шт.

REF

INSTRUCTION

DECAL - warning, avoid injury (See Page 9-337)

1шт.

REF

INSTRUCTION

DECAL - caution, improper unloading (See Page 9-337)

1шт.

REF

INSTRUCTION

DECAL - SMV (See Page 9-335)

1шт.

12

1327767C1

SELF-TAP SCREW,Hex Wshr Hd, 5/16" - 18 x 16mm

- self-tapping, hex washer head, polyseal, 5/16 NC x 5/8 inch

6шт.

15

140911C3

SHEET

SUPPORT - front panel (Prior to Serial Number 8922)

1шт.

15

1345001C1

SHEET

SUPPORT - front panel (Serial Number 8922 and after)(Shown)

1шт.

16

409-7624

BOLT,Hex Flg, 3/8" - 16 x 1 1/2", Spcl

4шт.

17

1261243C1

BAR

BRACKET - retaining

2шт.

18

409-7612

BOLT,3/8"-16 x 1.09" OAL

- hex serrated flange, 3/8 NC x 3/4 inch

6шт.

19

141211C2

SUPPORT

- cutoff wheel

1шт.

20

409-7612

BOLT,3/8"-16 x 1.09" OAL

- hex serrated flange, 3/8 NC x 3/4 inch

5шт.

21

141217C1

NUT

- retainer, 3/8 inch NC

5шт.

22

140898C2

ANGLE

BRACKET - fan support

1шт.

23

413-68

BOLT,Hex, 3/8" - 16 x 1/2", Gr 5

2шт.

24

231-5146

FLANGE NUT,3/8"-16

2шт.

27

1345271C1

STEP

- hopper (All except vertical folding 12 row narrow)(Replaces 95967C1)(Shown)

1шт.

27

1345272C1

STEP

- hopper (Vertical folding 12 row narrow) (Replaces 96268C1)

1шт.

28

439-5844

HEADED PIN,1/2" x 2 3/4", G5

PIN - headed, 1/2 x 2-3/4 inch

2шт.

29

1978738C1

HAIR PIN COTTER

3/16"

2шт.

30

91236C2

FUNNEL

BRACKET - step, left-hand

1шт.

31

91237C2

FUNNEL

BRACKET - step, right-hand

1шт.

32

935915R1

SHIM,33.02mm OD x 0.38mm Thk

- .015 inch thick

1шт.

33

413-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5

- hex, 1/2 NC x 1-1/4 inch

4шт.

34

231-5148

FLANGE NUT,Flg, USR, 1/2"-13

4шт.

35

M22613

SPACER,1/2" X-Strng Pipe x 1"

- pipe, 1/2 ID x 1 inch

2шт.

36

1250802C1

SPACER

- step, 26 mm (1-3/64 inch) long

2шт.

37

413-832

BOLT,Hex, 1/2" - 13 x 2", Gr 5

2шт.

38

231-5148

FLANGE NUT,Flg, USR, 1/2"-13

2шт.

39

144932C2

ANGLE

BRACKET - step support, left-hand

1шт.

40

1250793C4

ANGLE

BRACKET - step support, left-hand, left (Vertical folding 12 row narrow)

1шт.

41

144933C2

ANGLE

BRACKET - step support, right-hand

1шт.

42

1250794C3

ANGLE

BRACKET - step support, right-hand (Vertical folding 12 row narrow)

1шт.

43

434-612

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 3/4", Gr 5

BOLT - carriage, 3/8 NC x 3/4 inch

8шт.

44

413-618

BOLT,Hex, 3/8" - 16 x 1-1/8", Gr 5

2шт.

45

231-5146

FLANGE NUT,3/8"-16

10шт.
