Запчасти Case IH 900 (9-070) - AUXILIARY DRIVE/CARRYING WHEELS, CYCLO AIR TRAILING, 6 & 12 ROW NARROW PLATE TRAILING, 6 ROW NARROW (09) - CHASSIS/ATTACHMENTS

Схема запчастей Case IH 900 - (9-070) - AUXILIARY DRIVE/CARRYING WHEELS, CYCLO AIR TRAILING, 6 & 12 ROW NARROW PLATE TRAILING, 6 ROW NARROW (09) - CHASSIS/ATTACHMENTS
9
32
9
10
15
20
22
31
21
3
39
5
6
16
8
36
13
30
17a
11
14
23
26
25
34
4
33
35
1
40
12
41
2
18
7
27
17
24

Артикул

Название

Примечание

Количество

1

91247C2

RAIL

- wheel, straight, outer, straight, outer

2шт.

2

91254C2

RAIL

- wheel, offset, inner, offset, inner

2шт.

3

91242C2

CABLE TIE

TIE - wheel rail

2шт.

4

413-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5

- hex, 5/8 NC x 2-1/4 inch

8шт.

5

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

8шт.

6

425-1010

NUT,5/8"-11, G5

8шт.

7

233254A1

BEARING ASSY,25.55mm ID

BEARING - ball

4шт.

8

495-81191

WASHER,1 5/32" x 2" x .060"

- flat, 1-5/32 x 2 x 3/64 inch

4шт.

9

1250724C1

BAR

BRACKET - bearing

8шт.

10

433-628

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5

BOLT - carriage, 3/8 NC x 1-3/4 inch

8шт.

11

231-5146

FLANGE NUT,3/8"-16

8шт.

12

90376C2

SPACER

- sprocket

2шт.

13

149356C2

SPACER

- axle

1шт.

14

495-81027

WASHER,21/32" x 1 1/2" x .120"

- flat, 21/32 x 1-1/2 x 7/64 inch

4шт.

15

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

4шт.

16

1345045C1

BOLT,Spcl, Hex, 5/8" - 11 x 1 1/2"

BOLT - special

4шт.

17

90341C2

AXLE

BAR - axle wheel, 327 mm (12-7/8 inch) long, no longer available, order item 17A, 90341C3 axle bar and item 18, 495-81189 washer, below

2шт.

17a

90341C3

AXLE

BAR - axle wheel, 333 mm (13-1/8 inch) long

2шт.

18

495-81189

WASHER,1.16" ID x 1.75" OD x 0.03" Thk

- flat, 1-5/32 x 1-3/4 x 1/32 inch

1шт.

20

90343C1

HUB

- wheel

2шт.

21

T53527

WHEEL

- 381 (15) x 127 mm (5 inch) (For 7.60 x 15, 6 ply tire)

2шт.

22

810769C1

VALVE

- inflation

2шт.

23

549962R1

BOLT,1 1/2" - 20 x 1 1/2", Class 3

- hex conical, 1/2 NF x 1-5/32 inch

12шт.

24

1264481C1

SPACER,1/2" Pipe x 2.441"

- 62 mm (2-7/16 inch) long

16шт.

25

1264480C1

COVER

- 15 inch wheel

8шт.

26

413-896

BOLT,Hex, 1/2" - 13 x 6", Gr 5

- hex, 1/2 NC x 6 inch

8шт.

27

231-5148

FLANGE NUT,Flg, USR, 1/2"-13

8шт.

30

219-90

LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF

FITTING - grease, 45 degree, 1/4-28 special taper x 13/16 inch, 45 degree (Drive wheel rail assemblies only)

2шт.

31

95832C3

BRACKET

- wheel and cylinder mounting. left-hand

2шт.

32

95833C3

BRACKET

- wheel and cylinder mounting, right-hand

2шт.

33

219-6

LUBE NIPPLE,1/4" - 28 NPTF

FITTING - grease, straight, 1/4-28 taper x 9/16 inch, straight

4шт.

34

232-51310

FLANGE NUT,Flg, USR, 5/8"-12

- hex serrated flange, 5/8 inch NC, grade 8

2шт.

35

95911C2

TUBE

SPACER - bolt

2шт.

36

413-10112

BOLT,Hex, 5/8" - 11 x 7", Gr 5

- hex, 5/8 NC x 7 inch

2шт.

39

141025C2

BOLT

L-BOLT - 3/4 inch NC

4шт.

40

396-31081

WASHER,20.63mm ID x 38.1mm OD x 5.56mm Thk

4шт.

41

425-1012

NUT,3/4"-10, G5

- hex, 3/4 inch NC

8шт.

Выбрано товаров: 37
