(05-11) - WHEELS, CARRYING WHEELS SELECTOR VALVE, UNITS C, D, E, M, S AND T

Запчасти Case IH 800 (05-11) - WHEELS, CARRYING WHEELS SELECTOR VALVE, UNITS C, D, E, M, S AND T (06) - POWER TRAIN

Схема запчастей Case IH 800 - (05-11) - WHEELS, CARRYING WHEELS SELECTOR VALVE, UNITS C, D, E, M, S AND T (06) - POWER TRAIN
3
6
1
9
7
10
4
5
8
12
2
10
11
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

VALVE ASSY, level lift, for components see list of parts under details of level lift valve

1шт.

2

141405C1

HARNESS

tractor

1шт.

117142

FUSE,10 Amp, Type 3AG

cartridge type AGC 10 Amp

1шт.

3

117620C1

CABLE

1шт.

4

306132C1

CABLE TIE,14.5" L

STRAP, 14 in. tie

1шт.

5

141409C1

HARNESS

planter

1шт.

6

141401C2

TESTER

ELECTRIC CONTROL ASSY, level lift, fixed

1шт.

6

1264445C1

CONTROL

ELECTRIC CONTROL ASSY, level lift, adjustable

1шт.

7

149492C1

PLATE

W/PRODUCT GRAPHIC, control

1шт.

8

1250682C1

SWITCH

W/NUT

1шт.

9

57603C1

NUT

switch

1шт.

10

149456C91

SET

PACKAGE, 9 pin connector rings consists of 10 rings

1шт.

11

116270C1

PLUG

cyclo planters w/serial no. 10100 and below, plate planters w/serial no. 2313 and below

1шт.

11

1264374C1

PLUG

cyclo planters w/serial no. 10101 and above, plate planters w/serial no. 2314 and above

1шт.

12

169851C1

GROMMET

1шт.
