Запчасти Case IH 800 (11-05) - GRANULAR CHEMICAL, HERBICIDE SPREADER, REAR MOUNTED, ONE PER ROW, UNITS A THRU AB (09) - CHASSIS/ATTACHMENTS

1

HOSE, granular chemical, use 14 inches from bulk roll marked 1254166C1

1шт.

2

274085R91

HOSE CLAMP,#10, 0.56/1.06 Type F Worm

CLAMP, hose type F

1шт.

3

147360C2

DEFLECTOR

SPREADER ASSY, herbicide

1шт.

1254229C1

RIVET

oval hd semi-tubular zn

6шт.

12872R1

BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd

CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd

2шт.

120393

BEARING WASHER,5/16", SAE

WASHER, .344 x .688 x .051

2шт.

129-419

WING NUT,5/16"-18

NUT, 5/16-18 wing

2шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

Note A Hex, 5/16"-18 x 1", G5, Full Thd

4шт.

495-21031

WASHER,1/4"

.312 x .734 x .051, note A

4шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock, note A

1шт.

4

137101C1

SUPPORT

ASSY, spreader

1шт.

137185

COTTER PIN,1/8" x 1"

PIN, SPLIT (COTTER), 1/8" x 1"

2шт.

120394

WASHER,3/8", SAE

WASHER, .406 x .812 x .051

2шт.

5

650949C1

VALVE SPRING

SPRING, rear spreader

1шт.
