Запчасти Case IH 800 (04-03) - HITCH, FOLDING HITCH AND CONNECTIONS, UNITS C, D, E, M, S AND T (04) - ELECTRICAL SYSTEMS
№
Артикул
Название
Примечание
Количество
1
1279040C1
CLEVIS
hitch, replaces 1250770C2
1шт.
19866R1
BOLT,Hex, 3/4" - 10 x 6 1/2", Gr 5
3/4 x 6-1/2 type 5
1шт.
19959R1
BOLT,Hex, 3/4" - 10 x 7", Gr 5
3/4 x 7 type 5
1шт.
87340
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
WASHER, LOCK, 3/4"
2шт.
NLS
NO LONGER SERVICED
.812 x 1.469 x .108
1шт.
2
141095C1
ROD
support hose
1шт.
3
137098C1
SUPPORT
bracket pump mtg
1шт.
4
1250769C3
TUBE,125, 90 mm Length
ASSY, tongue
1шт.
28117R1
BOLT,Hex, 1" - 8 x 9 1/2", Gr 8
1 x 9-1/2 PHC type 8
1шт.
492-11100
LOCK WASHER,1"
WASHER, LOCK, 1"
1шт.
9849633
NUT,1"-8, G5
1шт.
5
1250754C1
SPACER
1шт.
6
1250775C2
PIN
ASSY, tongue 1 in.
1шт.
7
517843R1
COTTER PIN
PIN, qa cot.
1шт.
8
1250748C2
SPACER
tongue
3шт.
20575R1
BOLT,Hex, 3/4" - 10 x 8", Gr 5
3/4 x 8 type 5
3шт.
87340
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
WASHER, LOCK, 3/4"
3шт.
21211R1
WASHER
.781 x 1.500 x .164, 6 for units C, D, M, S and T
1шт.
1277824C1
WASHER
tongue spacer, square, 6 for unit E
1шт.
9
141241C1
JACK
ASSY
1шт.
10
1268044C92
TOW BAR
TONGUE W/PRODUCT GRAPHICS, hinge, units C, D, M and S
1шт.
10
1268045C92
TOW BAR
TONGUE W/PRODUCT GRAPHICS, hinge, units E and T
1шт.
1254170C1
DECAL
PRODUCT GRAPHIC, caution
1шт.
1254234C1
PRODUCT GRAPHIC,Caution To Prevent Personal Injury
caution
1шт.
1277910C1
PRODUCT GRAPHIC,Caution Always Use 7/8 in Hitch Pin
caution
1шт.
11
149420C1
GROMMET
1шт.
12
219-8
LUBE NIPPLE,1/4" - 28 NPTF
FITTING, 1/4-28 SAE lt lub
1шт.
13
1277870C91
CHAIN (AG)
PIN W/CHAIN ASSY, hitch
1шт.
14
373025R91
PIN ASSY.
PIN, quick attachable snap
1шт.
15
148558C1
CLEVIS
1шт.
271729
BOLT,Hex, 5/8" - 11 x 3 1/2", Gr 5
5/8 x 3-1/2 type 5
1шт.
19508R1
LOCK NUT,5/8"-11, GB
NUT, 5/8 pln p/t lock type 5
1шт.
26512R1
WASHER
.781 x 2.000 x .164
1шт.
Выбрано товаров: 35
