Запчасти Case IH 1260 (39.100.10) - FRAME - WING WHEEL (39) - FRAMES AND BALLASTING

1

87679784

FRAME

Wing Wheel Support

1шт.

2

84058863

SENSOR

1шт.

3

87553979

COLLAR CLAMP

Caster Shaft

1шт.

4

87688136

PIN

44.45 mm x 177.8 mm fl

2шт.

5

86624098

PIN,1/2" x 2 1/2", Coiled

4шт.

6

280120

BOLT,Hex, 3/4" - 10 x 6", Gr 5

1шт.

7

280375

NUT,3/4"-10, GC

2шт.

8

87694001

SHIELD

Wiring Harness

1шт.

9

9707580

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd

2шт.

10

523282

SERRATED NUT,Flg, USR, 1/4"-20

2шт.

11

87680050

HOUSING

Caster Pivot, Model Year 2010 And Before

1шт.

11

84354929

SUPPORT

Caster Pivot, Model Year 2011

1шт.

12

87414

LUBE NIPPLE,1/4" - 28

2шт.

13

87679777

GUIDE

Caster Lock Spring

1шт.

14

280285

BOLT,Hex, 1" - 8 x 4", Gr 5

1шт.

15

87304132

NUT,1"-8, GC

3шт.

16

87619402

GUIDE

Wing Wheel Spring Latch

1шт.

17

84142475

PLATE

Caster Lock

1шт.

18

87691330

PLATE

Caster Latch Lever

1шт.

19

87687193

LATCH

Caster Lock

1шт.

20

87680065

PLATE

Caster Lock

1шт.

21

87975

BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 5

2шт.

22

86992215

LOCK NUT,1/2"-13, GC

2шт.

23

86977759

BOLT,Hex, 3/4" - 10 x 3 1/2", Gr 5

1шт.

24

280183

BOLT,Hex, 5/8" - 11 x 4 1/2", Gr 5

1шт.

25

6395

LOCK NUT,5/8"-11, GB

1шт.

26

1254302C1

BUSHING,13.5mm ID x 22.2mm OD x 16.7mm L

link pivot

2шт.

27

87695475

PIN

19.05 mm x 37 mm ul

1шт.

28

7631

SNAP RING

external, .693" id x .042" thick

2шт.

29

80621023

SPRING

Compression .25" Wire, 1.625 od x 13.94" Long

1шт.

30

87706827

TRUNNION

Wing Caster

1шт.

31

84327152

BUSHING

2шт.

32

87687207

SHAFT

63.5 mm x 382 mm fl, Model Year 2010 And Before

1шт.

32

84393819

SHAFT

Model Year 2011

1шт.

33

84132158

CASTING

Walking Beam

2шт.

34

87671096

PIN

22.23 mm x 206 mm fl

2шт.

35

438-11624

ROLL PIN,6.35mm OD x 38.1mm L

4шт.

36

NSS

NOT SOLD SEPARAT

2шт.

See Figure 44.100.03

1шт.

37

87695504

TRUNNION

Caster Pivot, Years: -01-FEB-10

1шт.

37

84252975

TRUNNION

Caster Pivot, Start Year: 01-FEB-10

1шт.

38

88557

BOLT,Hex, 3/4" - 10 x 2", Gr 5, Full Thd

2шт.

39

86632592

WASHER,1.06" ID x 2" OD x 0.13" Thk

1шт.

40

87682410

BOLT

Hex, 1"-8 x 5 5/8", G8

1шт.

41

87671034

PAD

Caster Wear

1шт.

42

87708940

BUSHING

Composite 90 x 95 x 100 mm, Model Year 2010 And Before

2шт.

42

84327580

BUSHING

Composite 3.5 x 3.8 x 3.5, Model Year 2011

2шт.

43

87706868

BUSHING

CP 44.5 x 50.8 x 50.8 mm

4шт.

44

87715510

SPACER

94.9 mm od x 89.3 mm id x 193 mm Long

1шт.

45

280285

BOLT,Hex, 1" - 8 x 4", Gr 5

, Years: -01-FEB-10

1шт.

45

280443

BOLT,Hex, 1" - 8 x 4 1/2", Gr 5

, Start Year: 01-FEB-10

1шт.

46

84247092

BRACKET

Snubber

1шт.

47

84247091

PLATE

Spring

1шт.

48

87506208

COMPRESSION SPRING

5/16" wire 7/8" id x 3l

2шт.

49

84237929

PAD

Caster Snubber

1шт.

50

87972

BOLT,Hex, 1/2" - 13 x 2 1/2", Gr 5

1шт.

51

86632558

JAM NUT,Jam, 1/2"-13, G5

1шт.
