Запчасти Case IH 1250 (35.720.01[01]) - HYDRAULICS - DRIVE TRANSMISSION - 24 ROW (35) - HYDRAULIC SYSTEMS

1

87540733

BRACKET

seed drive

1шт.

2

87503169

SPROCKET

24 tooth 50 chain

1шт.

3

86624123

SET SCREW,Hex Skt, 1/2" - 13 x 1/2"

6шт.

4

87670751

BOLT

L 3/4"-10 242 mm x 242 mm

1шт.

5

86624163

WASHER,0.81" ID x 1.5" OD x 0.22" Thk

2шт.

6

280954

NUT,3/4"-10, G5

2шт.

7

87461605

MOTOR

49.17cm3 (3.0 in3) displacement

1шт.

8

86632598

HEX SOC SCREW,1/4" - 28 x 3/4"

3шт.

9

134158C92

BALL BEARING,22.5mm ID

7/8 hex flange

3шт.

10

87503164

SHAFT

transmission input 7/8" hex

1шт.

11

87503167

SPROCKET

16 tooth 50 chain

1шт.

12

86624169

WASHER,1.03" ID x 1.5" OD x 0.06" Thk

2шт.

13

86632577

SET SCREW,Hex Skt, 1/4" - 20 x 1/4"

2шт.

14

87463000

SENSOR

Assembly, Hydraulic Drive

1шт.

15

87402

COTTER PIN,1/4" OD x 1-1/4" OAL

2шт.

16

88992

CARRIAGE BOLT,Short Sq Nk, 5/16" - 18 x 1", Gr 5

4шт.

17

145458

SERRATED NUT,5/16"-18 GR 5 ZND

4шт.

18

87503116

SPROCKET

34 tooth, 50 chain

1шт.

19

87503166

SPROCKET

15 tooth 50 chain

1шт.

20

1791D

CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm

roller, #50 (10 foot bulk)

1шт.

Use 47 links

1шт.

20

87034815

LINK,15.88mm Pitch

#50 single pitch

1шт.

20

241-1715

LINK,15.88mm Pitch

#50 single pitch offset

1шт.

21

1791D

CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm

roller, #50 (10 foot bulk)

1шт.

Use 55 links

1шт.

21

87034815

LINK,15.88mm Pitch

#50 single pitch

1шт.

22

280348

CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3 1/2", Gr 5

2шт.

23

87505783

SLEEVE

tensioner pivot 10.33 mm id x 15.88 mm od x 60 mm long

2шт.

24

86521606

FLANGE NUT,Hex, 3/8" - 16, Gr 5

2шт.

25

87550916

TENSIONER

chain

2шт.

26

87505794

TORSION SPRING

idler, 4.7123mm dia. x 42.7 coil length, 8 coils, RH

2шт.

27

1277726C1

ROLLER,48mm OD x 34mm L

idler

2шт.

28

495-81178

WASHER,21/32" x 1 1/8" x .048"

2шт.

29

80754

COTTER PIN,3/16" OD x 1-1/2" OAL

2шт.
