(35.138.11) - HYDRAULICS - FAN VALVE, DIRECT DRIVE - MECHANICAL DRIVE

Запчасти Case IH 1250 (35.138.11) - HYDRAULICS - FAN VALVE, DIRECT DRIVE - MECHANICAL DRIVE (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 1250 - (35.138.11) - HYDRAULICS - FAN VALVE, DIRECT DRIVE - MECHANICAL DRIVE (35) - HYDRAULIC SYSTEMS
1
5
35.138.17
6
4
3
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87438424

VALVE

assembly bulk fill PTO with plugs

1шт.

2

80680

LOCK WASHER,3/8 0.381 CST ZND

3шт.

3

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3шт.

4

86508629

FITTING,Blkhd, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree

1шт.

5

9610690

FITTING,Blkhd, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree

1шт.

6

86513143

BHD LOCK NUT,Blkhd, 1 1/16"-12

1шт.

7

595460

BHD LOCK NUT,7/8" - 14

1шт.

Выбрано товаров: 7
