Запчасти Case IH 1250 (35.138.09) - HYDRAULICS - FAN VALVE - NON-AFS MACHINES (35) - HYDRAULIC SYSTEMS

1

9610690

FITTING,Blkhd, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree

1шт.

2

595460

BHD LOCK NUT,7/8" - 14

1шт.

3

86508629

FITTING,Blkhd, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree

1шт.

4

86513143

BHD LOCK NUT,Blkhd, 1 1/16"-12

1шт.

5

296823A2

VALVE

check

1шт.

6

86505980

BOLT,Hex, 3/8" - 16 x 4 1/2", Gr 5

2шт.

7

80680

LOCK WASHER,3/8 0.381 CST ZND

2шт.

8

9628503

NUT,3/8"-16, G5

2шт.
