Запчасти Case IH 1250 (75.110.47) - LIQUID FERTILIZER COULTER (75) - SOIL PREPARATION

100

84157031

Coulter Kit Number

1шт.

1

87677728

SUPPORT

Coulter RH

1шт.

Shown

1шт.

1

87677718

SUPPORT

Counter LH

1шт.

Not Shown

1шт.

2

87677731

ARM

Coulter RH Incl Jam Nut 425-1416

1шт.

Shown

1шт.

2

87677723

ARM

Coulter LH Incl Jam Nut 425-1416

1шт.

Not Shown

1шт.

3

87624379

BEARING LINER,38.27 mm ID x 50.88 mm OD x 25.4 mm

38.2mm ID x 50.8mm OD x 25.4mm Long

2шт.

4

36723

BEARING CUP,59.16mm OD x 11.81mm W

#LM67010

2шт.

5

36726

BEARING CONE,31.75mm ID x 16.76mm W

#LM67048

2шт.

5

84356153GV

BEARING

Value

2шт.

6

472222R1

SLEEVE

Wear 2.33" od

1шт.

7

472221R91

SEAL,39.57mm ID x 58.6mm OD x 7.37mm Thk

Hub Oil

1шт.

8

84224620

SPINDLE

Fertilizer Coulter

1шт.

9

519250R1

SLOTTED NUT

1 1/4"-12 Slotted

1шт.

10

86523955

COTTER PIN,1/8" x 2"

1шт.

11

87584013

BEARING LINER,25.634 mm ID x 31.87 mm OD x 12.7 mm

25.5mm ID x 31.8mm OD x 12.7mm Long

2шт.

12

87663514

ARM

Single Disk Opener Gauge RH

1шт.

Shown

1шт.

12

87663513

ARM

Single Disk Opener Gauge LH

1шт.

Not Shown

1шт.

13

87023159

WASHER,0.64" ID x 1.05" OD x 0.13" Thk

1шт.

14

87628246

WHEEL

2" x 13" Offset

1шт.

15

87584040

BLADE

Coulter 381mm x 5mm Thick

1шт.

16

87023126

BOLT,Hex, 5/8" - 11 x 3", LH Thread, Gr 5

1шт.

RH Coulter

1шт.

16

87338

BOLT,Hex, 5/8" - 11 x 3", Gr 5

1шт.

LH Coulter

1шт.

17

87010473

HEX SOC SCREW,FLAT, 1/2" - 13 x 7/8"

Cap 1/2"-13 x 7/8"

4шт.

18

80710

LUBE NIPPLE,1/8” – 27 Dryseal PTF

2шт.

19

86637951

WASHER,0.81" ID x 3" OD x 0.24" Thk

1шт.

20

88692

BOLT,Hex, 3/4" - 10 x 1 1/2", Gr 5, Full Thd

1шт.

21

87584022

PIN

Gauge Wheel Mount

1шт.

22

87599601

KEY

Square 1/4" x 2 1/4" Long

1шт.

23

86625245

WASHER,0.52" ID x 2" OD x 0.16" Thk

.521 ID x 2.0 OD x .160 Thick

1шт.

24

80679

LOCK WASHER,1/20.507 CST ZND

1шт.

25

87689

BOLT,1/2"-13 x 1.813" OAL, Gr 5

1шт.

26

87584046

EYEBOLT

5/8"-11 x 5" Long

1шт.

27

86624189

WASHER,0.66" ID x 1.31" OD x 0.15" Thk

2шт.

28

85700693

NUT,5/8" - 11, Gr C

1шт.

29

86625068

NUT,5/8"-11, G8

1шт.

30

87652325

BRACKET

Scraper Pivot RH

1шт.

Shown

1шт.

30

87652326

BRACKET

scraper pivot LH

1шт.

Not Shown

1шт.

31

9707516

BOLT,1/2"-13 x 1-3/4", Cl 5

2шт.

32

87333862

NUT

1/2"-13, GB

2шт.

33

86632570

HEADED PIN

3/8" x 3 1/4"

1шт.

34

87584044

SCRAPER

Single Disk RH

1шт.

Shown

1шт.

34

84423068

SCRAPER BLADE

Single Disk RH, Model Year 2013

1шт.

34

87600205

SCRAPER

Single Disk LH

1шт.

Not Shown

1шт.

34

84423071

SCRAPER BLADE

Single Disk LH, Model Year 2013

1шт.

35

87677698

TUBE

Fertilizer, Years: -01-MAR-13

1шт.

RH

1шт.

35

87677697

TUBE

fertilizer, Years: -01-MAR-13

1шт.

LH

1шт.

35

84421408

BRACKET

Fertilizer Tube, RH, Start Year: 01-MAR-13

1шт.

35

84421411

BRACKET

Fertilizer Tube, LH, Start Year: 01-MAR-13

1шт.

36

280430

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5, Full Thd

2шт.

37

86632583

WASHER,1.28" ID x 2" OD x 0.12" Thk

2шт.

38

480344R1

EYEBOLT,Spring, 5/8" - 11 x 299.70mm

Bolt, Eye 5/8"-11 Spring, Years: -01-MAR-13

1шт.

38

84194013

EYEBOLT

5/8" x 11.8", Start Year: 01-MAR-09

1шт.

39

20090050

HOLDER

Spring

2шт.

40

24143880

COMPRESSION SPRING

20, Coulter

1шт.

41

86624072

HEADED PIN,12.7mm OD x 69.85mm L

1шт.

42

84158486

WASHER,0.53" ID x 1.25" OD x 0.19" Thk

1шт.

43

87397

COTTER PIN,3/16" OD x 1" L

1шт.

44

87613192

WASHER,0.66" ID x 1.75" OD x 0.24" Thk

1шт.

45

280374

NUT,Hex, 5/8" - 11, Gr 5

2шт.

46

80755

COTTER PIN,1/8" OD x 1" L

1шт.

47

9628503

NUT,3/8"-16, G5

1шт.

48

80280644

BOLT,Hex, 3/8" - 16 x 2", Gr 5, Full Thd

1шт.

49

87505175

DUST CAP

H517 & H611

1шт.

50

87584047

PIN

12.7mm x 35mm - Depth Adjust

1шт.

51

87742350

ROLL PIN

Spiral 3/16" x 1 1/2"

1шт.

52

87584046

EYEBOLT

5/8" - 11 x 5" Long

1шт.
