Запчасти Case IH 1250 (75.110.35) - LIQUID FERTILIZER - TANK AND FRAME - 24 ROW, 600 GALLON TANK (75) - SOIL PREPARATION

1

87652309

FRAME

fertilizer tank, 600 gallon

1шт.

2

87503060

U-BOLT

us 3/4"-10 x 8.1 wide x 17.75 deep

2шт.

3

280954

NUT,3/4"-10, G5

4шт.

4

142583A1

U-BOLT

us 5/8"-11 7"w 4 7/32"d G5 2" thread

2шт.

5

85700693

NUT,5/8" - 11, Gr C

4шт.

6

87607560

TANK

600 gallon

1шт.

7

87647049

PLATE

strap anchor

6шт.

8

87660684

STRAP

600 gallon fertilizer tank

3шт.

9

87657981

BOLT

3/8"-16 x 5", G5, Full thread

12шт.

10

231-1446

NUT,3/8" - 16, Gr 5

12шт.
