Запчасти Case IH 1250 (75.110.18) - LIQUID FERTILIZER - TANK AND FRAME - 16 ROW, 600 GALLON TANK (75) - SOIL PREPARATION

1

87652310

SUPPORT

600 gallon liquid fertilizer

1шт.

2

87607560

TANK

600 gallon

1шт.

3

87647049

PLATE

strap anchor

6шт.

4

87660684

STRAP

600 gallon fertilizer tank

3шт.

5

87657981

BOLT

3/8"-16 x 5", G5, Full thread

12шт.

6

231-1446

NUT,3/8" - 16, Gr 5

12шт.

7

9706701

BOLT,Hex, 3/4" - 10 x 2 1/2", Gr 5

3шт.

8

231-42412

NUT,3/4"-10, GB

3шт.

9

248070A1

U-BOLT

BOLT "U" us 5/8"-11 x 177 mm wide x 233.5 mm deep

2шт.

10

280374

NUT,Hex, 5/8" - 11, Gr 5

4шт.
