Запчасти Case IH 1240 (35.310.01) - LAYOUT HYD HOSES ROUTING 12 ROW (35) - HYDRAULIC SYSTEMS

1

427745A2

BAR

vacuum support

4шт.

2

87447161

BRACKET

hose routing

4шт.

Used with "Marker" Option

1шт.

3

86625035

CLAMP,12.7mm, Coat, 7.1mm Bolt Hole, P Type

1шт.

4

87023168

CLAMP,44.4mm, Coat, 7.1mm Bolt Hole, P Type

1 3/4", Insul, 1/4" Bolt

2шт.

5

86625061

NUT,1/4"-20, GB

10шт.

Used with "Marker" Option

1шт.

5

86625061

NUT,1/4"-20, GB

4шт.

Used with "No Marker" Option

1шт.

6

86505867

BOLT,Hex, 1/4" - 20 x 1", Gr 5

2шт.

7

87446922

PLATE

hydraulic hose routing

2шт.

Used with "Marker" Option

1шт.

8

523291

BOLT,Hex Serr Flg, 1/4" - 20 x 1/2"

8шт.

Used with "Marker" Option

1шт.

8

523291

BOLT,Hex Serr Flg, 1/4" - 20 x 1/2"

4шт.

Used with "No Marker" Option

1шт.

9

427781A1

HOSE CLAMP

2 hose

2шт.

Used with "Marker" Option

1шт.

10

87446920

PLATE

hydraulic hose routing

1шт.

11

87446924

PLATE

hydraulic hose routing

1шт.

12

529070

CABLE TIE,368.3mm L

CABLE STRAP

4шт.

Used with "Marker" Option

1шт.

13

529070

CABLE TIE,368.3mm L

CABLE STRAP

7шт.

14

86512175

BOLT,Hex Serr Flg, 3/8" - 16 x 1 1/2"

2шт.

Used with "Marker" Option

1шт.

15

247780

SERRATED NUT,Flg, USR, 3/8"-16

2шт.

Used with "Marker" Option

1шт.
