Запчасти Case IH 1240 (35.138.09) - LAYOUT NO MARKER OPTION VALVE MOUNT - 24 ROW (35) - HYDRAULIC SYSTEMS

1

87582248

VALVE

bi-directional solenoid

1шт.

2

9840

U-BOLT

us 5/16"-18 x 2 1/16" w x 2 3/4" d thread G5

1шт.

3

86050277

NUT,5/16"-18, GB

2шт.

4

86071

HYD CONNECTOR,7/8" - 14 JIC x 3/4" - 16 ORB

1шт.

5

182977

90 ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree Fem Sw

1шт.

6

128818

UNION,3/4" - 16 ORB x 3/4" - 16 JIC

1шт.

7

86513015

TEE,3/4" - 16 JIC x 3/4" - 16 JIC x 3/4" - 16 JIC

1шт.

8

248992

45 ELBOW,45 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree Fem Sw

1шт.

9

128830

90 ELBOW,3/4" - 16 JIC x 3/4" - 16 ORB

2шт.

10

91241C1

HYDRAULIC HOSE,12.70 mm ID x 5080.00 mm, SAE 100R1

1шт.

11

91202C1

HYDRAULIC HOSE,12.70 mm ID x 2160.00 mm, SAE 100R1

1шт.

12

410538A1

HYDRAULIC HOSE

5/8" x 94" fl

1шт.
