Запчасти Case IH 1240 (35.138.06) - LAYOUT VALVE MARKER MOUNTING 24 ROW (35) - HYDRAULIC SYSTEMS

1

401592A1

VALVE, CONTROL

assembly marker

1шт.

2

80680

LOCK WASHER,3/8 0.381 CST ZND

3шт.

3

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3шт.

4

87301330

HYD CONNECTOR,7/8" - 14 ORB x 7/8" - 14 JIC

5/8" mb x 5/8" mj

2шт.

Includes O-Ring

1шт.

5

182977

90 ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree Fem Sw

2шт.

6

128817

HYD CONNECTOR,3/4" - 16 ORB x 9/16" - 18 JIC

5шт.

Includes O-Ring

1шт.

7

128818

UNION,3/4" - 16 ORB x 3/4" - 16 JIC

2шт.

Includes O-Ring

1шт.

8

84313

ELBOW,45 Degree, 9/16"-18, 37 Degree x 3/4"-16, O-Ring

1шт.

Includes O-Ring

1шт.

9

216797

45 ELBOW,45 Degree, 3/4"-16, 37 Degree x 3/4"-16, O-Ring

1шт.

Includes O-Ring

1шт.

10

237-8006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 8, 90 Duro

1шт.

11

1547188C1

SWITCH

pressive inv

1шт.

12

410538A1

HYDRAULIC HOSE

5/8" x 94" fl

1шт.

13

410538A1

HYDRAULIC HOSE

5/8" x 94" fl

1шт.

14

1284314C1

HYDRAULIC HOSE

3/8" x 235" fl

1шт.

15

1284314C1

HYDRAULIC HOSE

3/8" x 235" fl

1шт.

16

1284314C1

HYDRAULIC HOSE

3/8" x 235" fl

1шт.

17

91202C1

HYDRAULIC HOSE,12.70 mm ID x 2160.00 mm, SAE 100R1

1шт.

18

1284299C1

HYDRAULIC HOSE

3/8" x 350" (8890 mm)

1шт.

19

1284299C1

HYDRAULIC HOSE

3/8" x 350" (8890 mm)

1шт.

20

91241C1

HYDRAULIC HOSE,12.70 mm ID x 5080.00 mm, SAE 100R1

1шт.

21

1284299C1

HYDRAULIC HOSE

3/8" x 350" (8890 mm)

1шт.

22

167269

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

23

128825

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1шт.
