Запчасти Case IH 1240 (75.110.07) - LIQUID FERTILIZER SYSTEM W/TRACTOR MOUNTED TANKS - FITTINGS & VALVES (75) - SOIL PREPARATION

1

NSS

NOT SOLD SEPARAT

FERTILIZER 4 VALVE BANK

1шт.

12/23 row, 16/31 row and 24 row planters

1шт.

2

NSS

NOT SOLD SEPARAT

FERTILIZER 2 VALVE BANK

1шт.

12 row and 16 row planters

1шт.

3

406041A1

CLAMP,58.51mm

1" flange banjo #fc100

2шт.

4

86987616

FITTING,2" Flange x 1" Hose Barb

2" flange x 1" barb

5шт.

5

408350A1

MANIFOLD GASKET,1" EPDM Manifold Gasket

1" x 7/32" thick

14шт.

8

405785A1

ELBOW

poly 90º 1" flange x 3/4" hb

3шт.

10

BN303204

GASKET,1-1/2" EPDM Gasket

2 7/32" od x 1 41/64" id x 1/4" thick

4шт.

16

406041A1

CLAMP,58.51mm

1" flange banjo #fc100

14шт.

18

513309

HOSE CLAMP,1-1/16” - 2”, Worm Gear

2шт.

19

86536660

HOSE CLAMP,25mm - 44mm

2шт.

20

408355A1

HOSE,1.00" ID x 10.00"

Rubber

1шт.

21

405798A1

STRAINER ELEMENT,AAH

fitting poly y 2" line 80 mesh

1шт.

21

87413266

SCREEN,80 Mesh Screen

Strainer 80 Mesh, Banjo Part# LS280, Blue

1шт.

21

87413267

GASKET,2" EPDM Gasket

strainer

1шт.

22

405783A1

FITTING,2" Flange x 1-1/4" 90 Degree Hose Barb Elbow

poly 90º 2" flange x 1 1/4" hose barb

1шт.

23

434039A1

FITTING,2" Flange x 1-1/2" Hose Barb

2" Manifold x 1 1/2" hb Poly, Banjo

1шт.

24

603022

CLAMP,44.4mm, Coat, 10.3mm Bolt Hole, P Type

2шт.

25

86984447

HOSE,1.25" ID BULK x 100.00'

1шт.

26

403008A1

PUMP

diaphram low pressure

1шт.

26

87462811

SEAL KIT

pump o-ring complete 9910-KIT2365

1шт.

27

1264065C1

HOSE

pvc 1 1/2" id x 1 3/4" od x 1'

1шт.

28

86050202

HOSE CLAMP,1.59” - 2.5”, Worm Gear

3шт.

37

87413269

U-BOLT

ur 3/8"-16 x 2 1/2" wide x 4" deep ss with 1 3/4" thread

2шт.

38

86985855

LOCK NUT

3/8"-16 ss 1-way, nylon insert

4шт.

39

86993466

HOSE,0.75" ID

Order in Multiples of 100

1шт.
