Запчасти Case IH CONCORD (B08) - WING FRAMES, 40 FOOT

1

1033174

FRAME

WLDMT - wing, LH 40' (Serial #CBK0015002-CBK0015028)

1шт.

1

290794A1

FRAME ASSY

WING/W 40' LH

1шт.

2

1033175

FRAME

WLDMT - wing, RH 40' (Serial #CBK0015002-CBK0015028)

1шт.

2

290795A1

FRAME ASSY

WING/W 40' RH (Shown)

1шт.

3

1033164

SUPPORT ASSY.

WLDMT - marker sup. LH (Serial #CBK0015002-CBK0015028)

1шт.

4

1033165

SUPPORT ASSY.

WLDMT - marker sup. RH (Serial #CBK0015002-CBK0015028)

1шт.

5

1033167

FRAME

WLDMT - frame extension (Serial #CBK0015002-CBK0015028)

1шт.

6

1013348

BOLT

BOLT - hex: .75 x 6.00 NC Gr5 ZP (Serial #CBK0015002-CBK0015028)

4шт.

7

232-14412

NUT,3/4"-10, GB

NUT - nylock: .75 NC Gr6 ZP (Serial #CBK0015002-CBK0015028)

32шт.

8

1015235

PIN

WLDMT - hinge pin (Serial #CBK0015002-CBK0015028)

2шт.

8

290791A1

PIN

- hinge/W

4шт.

9

1016950

WASHER

- flat: SAE 1.25 ZP

10шт.

10

1018629

U-BOLT

BOLT US .75 4.031W 5.625D (Serial #CBK0015002-CBK0015028)

6шт.

11

1016663

WASHER

- flat: SAE 1.00 ZP

6шт.

12

1016669

PIN

WLDMT - pin, 1" x 7"

3шт.

13

1016727

SPLIT PIN/SAFETY PIN

PIN - cotter: .25 x 2.50 ZP

6шт.

14

1033168

BAR

WLDMT - toolbar, LH (Serial #CBK0015002-CBK0015028)

1шт.

14

290788A1

BAR

TOOLBAR/W LH

1шт.

15

1033169

BAR

WLDMT - toolbar, RH (Serial #CBK0015002-CBK0015028)

1шт.

15

290789A1

BAR

TOOLBAR/W RH (Shown)

1шт.

16

1016675

PIN

WLDMT - pin, 1" x 5"

1шт.

17

1016673

PIN

WLDMT - pin, 1" x 3 1/4"

2шт.

18

1033136

LINK

BAR - link (Serial #CBK0015002-CBK0015028)

2шт.

18

290806A1

LINK/W

2шт.

19

1033200

CYLINDER

WLDMT - cylinder arm (Serial #CBK0015002-CBK0015028)

2шт.

19

290781A1

ARM

CYLINDER ARM/W

2шт.

20

1016944

PIN

COTTER: .25 x 2.00 ZP

4шт.
