Запчасти Case IH ATX400 (8.050.1) - HOSE CONNECTORS - AIR DRILL AND TOW BEHIND SEEDER Related Equipment

1

214-1444

HOSE CLAMP,58.6mm - 82.5mm

3шт.

2

88011

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

2шт.

3

9706689

BOLT,Hex, 3/8" - 16 x 1 3/4", Gr 5

1шт.

4

87398

COTTER PIN,3/16" OD x 1-1/4" OAL

2шт.

5

80012047

BOLT,Hex, 3/8" - 16 x 4", Grade 5

1шт.

6

280736

NUT,5/16"-18, GC

2шт.

7

88902

NUT,3/8"-16

6шт.

8

280980

NUT,7/16"-14, GC

1шт.

9

280129

NUT,1/4"-20

2шт.

10

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

2шт.

11

88604

BOLT,Hex, 7/16" - 14 x 2 1/2", Gr 5

1шт.

12

88436

BOLT,Hex, 3/8" - 16 x 2", Gr 5

2шт.

13

3236

SELF-TAP SCREW

1/4"-20 x 1 1/4" oh pi plt

2шт.

14

425289A1

FOAM

1/2" wide x 3/16" thick - bulk

1шт.

15

4630

RIVET,Pop, 3/16" x .690"

4шт.

16

5625

LATCH

clamp over center

2шт.

17

87325926

WASHER,0.62" ID x 1.12" OD x 0.05" Thk

5/8" id x 1 1/8" 18ga

2шт.

18

87016560

JAM NUT,Jam, 3/8"-16, G5

4шт.

19

87019495

SNAP RING,#98, Ext

4шт.

20

6711

HITCH PIN

3/4" x 4" usable

2шт.

21

302676A1

LINCH PIN

4.76 mm x 31.75 mm long

2шт.

22

7938

U-BOLT

ur 5/16"-18 x 1 3/8" w x 1 5/8" d

1шт.

23

GD-254

COVER

plate hose connect

1шт.

24

GD-672A

HOLDER

quick connect 2 1/2" female

1шт.

25

GE-202

CLAMP

for two 3/4" couplers

1шт.

26

87500513

FORK

alignment

1шт.

27

DR-572

BRACKET

hyd. / elec. mount

1шт.

28

DR-860

LINK

air cart tow

2шт.

29

GH-601

COUPLING

hydraulic mount third line

1шт.

30

87420397

PIN,25.4mm OD x 122mm L

1" x 4 3/16" ul

2шт.

31

GE-519

BRACKET

mount, quick connect

1шт.

32

GH-139

BRACKET

plug support

1шт.
