Артикул
Название
Примечание
Количество
1
1337307C1
ARM
- gauge wheel, section number 6
1шт.
2
1337423C1
BUSHING
- pivot, arm to lift link
1шт.
3
1337302C1
BUSHING
TUBE AND BUSHING -, Serial Range: arm-frame
2шт.
4
219-8
LUBE NIPPLE,1/4" - 28 NPTF
NIPPLE, LUBE, , straight 1/4"-28 NPT x .54" lg
2шт.
5
271723
SNAP RING,Hex, 5/8" - 11 x 2", Gr 5
- hex head, 5/8" - 11 NC x 2"
6шт.
6
492-11062
BEARING WASHER,5/8"
WASHER, LOCK, 5/8"
6шт.
8
1337305C1
LINK
- gauge wheel arm to lift arm, see reference 11, page 9-107
1шт.
9
1337377C1
BOLT
-, Serial Range: link-arm
1шт.
10
28748R1
LOCK NUT,1 1/4"-7, G5
NUT - hex, self-locking, link bolt
1шт.
11
89055C1
BOLT
EYEBOLT - cylinder mounting
1шт.
12
272140
BOLT,Jam, 1 1/4"-7, G5
- hex jam, 1-1/4" - 7 NC
1шт.
13
180191
BOLT,Hex, 1/2" - 13 x 3 1/4", Gr 5
- hex head, 1/2" - 13 NC x 3-1/4"
1шт.
14
120384
WASHER,1/2"
LOCK, 1/2"
1шт.
15
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
1шт.
16
REF
INSTRUCTION
SPINDLE - hub, 6 bolt, see page 9-7 for hub and bearings
1шт.
Выбрано товаров: 16
